P.17.16
SEL-411L Relay Protection Manual Date Code 20151029
Analog Quantities
Quantities Listed Alphabetically
UBD Demand B-phase apparent power Megavoltamps [MVA]
(primary)
UBPKD Peak demand B-phase apparent power Megavoltamps [MVA]
(primary)
UC C-phase apparent power Megavoltamps [MVA]
(primary)
UCD Demand C-phase apparent power Megavoltamps [MVA]
(primary)
UCPKD Peak demand C-phase apparent power Megavoltamps [MVA]
(primary)
V1A 10-cycle average positive-sequence voltage angle Degrees [°] (±180°)
V1FIA Positive-sequence instantaneous voltage angle Degrees [°] (±180°)
V1FIM Positive-sequence instantaneous voltage magnitude Volts [V] (secondary)
V1M 10-cycle average positive-sequence voltage magnitude Kilo-volts [kV] (primary)
V1YPMA Positive-sequence synchrophasor voltage angle, Terminal Y Degrees [°] (±180°)
V1YPMAD Positive-sequence synchrophasor voltage angle, Terminal Y, delayed for RTC
alignment
Degrees [°] (±180°)
V1YPMI Positive-sequence synchrophasor voltage imaginary component, Terminal Y Kilo Volts [kV] (primary)
V1YPMID Positive-sequence synchrophasor voltage imaginary component, Terminal Y,
delayed for RTC alignment
Kilo Volts [kV] (primary)
V1YPMM Positive-sequence synchrophasor voltage magnitude, Terminal Y Kilo Volts [kV] (primary)
V1YPMMD Positive-sequence synchrophasor voltage magnitude, Terminal Y, delayed for
RTC alignment
Kilo Volts [kV] (primary)
V1YPMR Positive-sequence synchrophasor voltage real component, Terminal Y Kilo Volts [kV] (primary)
V1YPMRD Positive-sequence synchrophasor voltage real component, Terminal Y, delayed
for RTC alignment
Kilo Volts [kV] (primary)
V1ZPMA Positive-sequence synchrophasor voltage angle, Terminal Z Degrees [°] (±180°)
V1ZPMAD Positive-sequence synchrophasor voltage angle, Terminal Z, delayed for RTC
alignment
Degrees [°] (±180°)
V1ZPMI Positive-sequence synchrophasor voltage imaginary component, Terminal Z Kilo Volts [kV] (primary)
V1ZPMID Positive-sequence synchrophasor voltage imaginary component, Terminal Z,
delayed for RTC alignment
Kilo Volts [kV] (primary)
V1ZPMM Positive-sequence synchrophasor voltage magnitude, Terminal Z Kilo Volts [kV] (primary)
V1ZPMMD Positive-sequence Synchrophasor voltage magnitude, Terminal Z, delayed for
RTC alignment
Kilo Volts [kV] (primary)
V1ZPMR Positive-sequence synchrophasor voltage real component, Terminal Z Kilo Volts [kV] (primary)
V1ZPMRD Positive-sequence synchrophasor voltage real component, Terminal Z, delayed
for RTC alignment
Kilo Volts [kV] (primary)
VA1YFA Terminal Y, positive-sequence filtered voltage, angle Degrees [°] (±180°)
VA1YFI Terminal Y, positive-sequence filtered voltage, imaginary component Volts [V] (secondary)
VA1YFM Terminal Y, positive-sequence filtered voltage, magnitude Volts [V] (secondary)
VA1YFR Terminal Y, positive-sequence filtered voltage, real component Volts [V] (secondary)
VA1ZFA Terminal Z, positive-sequence filtered voltage, angle Degrees [°] (±180°)
VA1ZFI Terminal Z, positive-sequence filtered voltage, imaginary component Volts [V] (secondary)
VA1ZFM Terminal Z, positive-sequence filtered voltage, magnitude Volts [V] (secondary)
Table 17.1 Alphabetical List of Analog Quantities (Sheet 16 of 19)
Analog Quantities Phase, Phase-to-Phase and Sequence Quantities Units
