Date Code 20151029 Protection Manual SEL-411L Relay
Analog Quantities
Quantities Listed Alphabetically
VA1ZFR Terminal Z, positive-sequence filtered voltage, real component Volts [V] (secondary)
VABFA A-phase 10-cycle average fundamental phase-to-phase voltage angle Degrees [°] (±180°)
VABFM A-phase 10-cycle average fundamental phase-to-phase voltage magnitude Kilo-volts [kV] (primary)
VABRMS A-phase 10-cycle average rms phase-to-phase voltage magnitude Kilo-volts [kV] (primary)
VAFA A-phase 10-cycle average fundamental phase voltage angle Degrees [°] (±180°)
VAFIA A-phase filtered instantaneous voltage angles Degrees [°] (±180°)
VAFIM Filtered instantaneous A-phase voltage magnitude Volts [V] (secondary)
VAFM A-phase 10-cycle average fundamental phase voltage magnitude Kilo-volts [kV] (primary)
VARMS A-phase 10-cycle average rms phase-voltage Kilo-volts [kV] (primary)
VAYFA A-phase Terminal Y, filtered voltage, angle Degrees [°] (±180°)
VAYFI A-phase Terminal Y, filtered voltage, imaginary component Volts [V] (secondary)
VAYFM A-phase Terminal Y, filtered voltage, magnitude Volts [V] (secondary)
VAYFR A-phase Terminal Y, filtered voltage, real component Volts [V] (secondary)
VAYPMA Synchrophasor voltage angle, A-phase, Terminal Y Degrees [°] (±180°)
VAYPMAD Synchrophasor voltage angle, A-phase, Terminal Y, delayed for RTC alignment Degrees [°] (±180°)
VAYPMI Synchrophasor voltage imaginary component, A-phase, Terminal Y Kilo Volts [kV] (primary)
VAYPMID Synchrophasor voltage imaginary component, A-phase, Terminal Y, delayed for
RTC alignment
Kilo Volts [kV] (primary)
VAYPMM Synchrophasor voltage magnitude, A-phase, Terminal Y Kilo Volts [kV] (primary)
VAYPMMD Synchrophasor voltage magnitude, A-phase, Terminal Y, delayed for RTC alignment Kilo Volts [kV] (primary)
VAYPMR Synchrophasor voltage real component, A-phase, Terminal Y Kilo Volts [kV] (primary)
VAYPMRD Synchrophasor voltage real component, A-phase, Terminal Y, delayed for RTC
alignment
Kilo Volts [kV] (primary)
VAZFA A-phase, Terminal Z, filtered voltage, angle Degrees [°] (±180°)
VAZFI A-phase, Terminal Z, filtered voltage, imaginary component Volts [V] (secondary)
VAZFM A-phase, Terminal Z, filtered voltage, magnitude Volts [V] (secondary)
VAZFR A-phase, Terminal Z, filtered voltage, real component Volts [V] (secondary)
VAZPMA Synchrophasor voltage angle, A-phase, Terminal Z Degrees [°] (±180°)
VAZPMAD Synchrophasor voltage angle, A-phase, Terminal Z, delayed for RTC alignment Degrees [°] (±180°)
VAZPMI Synchrophasor voltage imaginary component, A-phase, Terminal Z Kilo Volts [kV] (primary)
VAZPMID Synchrophasor voltage imaginary component, A-phase, Terminal Z, delayed for
RTC alignment
Kilo Volts [kV] (primary)
VAZPMM Synchrophasor voltage magnitude, A-phase, Terminal Z Kilo Volts [kV] (primary)
VAZPMMD Synchrophasor voltage magnitude, A-phase, Terminal Z, delayed for RTC alignment Kilo Volts [kV] (primary)
VAZPMR Synchrophasor voltage real component, A-phase, Terminal Z Kilo Volts [kV] (primary)
VAZPMRD Synchrophasor voltage real component, A-phase, Terminal Z, delayed for RTC
alignment
Kilo Volts [kV] (primary)
VBCFA B-phase 10-cycle average fundamental phase-to-phase voltage angle Degrees [°] (±180°)
VBCFM B-phase 10-cycle average fundamental phase-to-phase voltage magnitude Kilo-volts [kV] (primary)
VBCRMS B-phase 10-cycle average rms phase-to-phase voltage magnitude Kilo-volts [kV] (primary)
VBFA B-phase 10-cycle average fundamental phase voltage angle Degrees [°] (±180°)
VBFIA B-phase filtered instantaneous voltage angles Degrees [°] (±180°)
Table 17.1 Alphabetical List of Analog Quantities (Sheet 17 of 19)
Analog Quantities Phase, Phase-to-Phase and Sequence Quantities Units
