Sel 411L - Page 1101

Date Code 20151029 SEL-411L Relay
SEL-411L Relay Command Summary
Command
a
,
b
Description
2ACCESS Go to Access Level 2 (complete relay monitoring and control).
89CLOSE Assert the disconnect 89CCm (m = 1–8) Control Relay Word bits.
89OPEN Assert the disconnect 89OCm (m = 1–8) Control Relay Word bits.
AACCESS Go to Access Level A (automation control).
ACCESS Go to Access Level 1 (monitor relay).
BACCESS Go to Access Level B (monitor relay and control circuit breakers).
BNAME ASCII names of all relay status bits (Fast Meter).
BREAKER n Display the circuit breaker report and breaker history; preload and reset breaker monitor data
(n = 1 is BK1; n = 2 is BK2).
CASCII Generate the Compressed ASCII response configuration message.
CBREAKER BREAKER command for the Compressed ASCII response.
CEVENT EVENT command for the Compressed ASCII response.
CHISTORY HISTORY command for the Compressed ASCII response.
CLOSE n Close the circuit breaker (n = 1 is BK1; n = 2 is BK2).
COM 87L Displays communications channel statistics.
COMM c Display relay-to-relay M
IRRORED BITS communications or remote synchrophasor data (c = A is
Channel A; c = B is Channel B; c = M is either enabled single channel; c = RTC for remote synchropha-
sors).
COM RTC Display statistics for synchrophasor client channels.
CONTROL nn Set, clear, or pulse an internal remote bit (nn is the remote bit number from 01–32).
COPY m n Copy settings between instances in the same class (m and n are instance numbers; for example: m = 1 is
Group 1; n = 2 is Group 2).
CPR Access signal profile data for up to 20 user-selectable analog values.
CSER SER command for the Compressed ASCII response.
CSTATUS STATUS command for the Compressed ASCII response.
CSUMMARY SUMMARY command for the Compressed ASCII response.
DATE Display and set the date.
DNAME X ASCII names of all relay digital I/O (Fast Meter).
DNP Display serial port DNP3 settings.
ETHERNET Displays Ethernet port (Port 5) configuration and status.
EVENT Display and acknowledge event reports.
EXIT Terminates a Telnet session.
FILE Transfer data between the relay and external software.
GOOSE Displays transmit and receive GOOSE messaging information.
GROUP Display the active group number or select the active group.
HELP Display available commands or command help at each access level.
HISTORY View event summaries/histories; clear event data.
ID Display the firmware id, user id, device code, part number, and configuration information.
