SEL-411L Relay Date Code 20151029
SEL-411L Relay Command Summary
IRIG Directs the relay to use the most available demodulated IRIG-B time code.
LOOPBACK Connect M
IRRORED BITS data from transmit to receive on the same port.
MAC Displays the Media Access Control address.
MAP 1 View the relay database organization.
METER Display metering data and internal relay operating variables.
OACCESS Go to Access Level O (output control).
OPEN n Open the circuit breaker (n = 1 is BK1; n = 2 is BK2).
PACCESS Go to Access Level P (protection control).
PASSWORD Change relay passwords.
PING Determines if the network is properly connected.
PORT Connect to a remote relay via M
IRRORED BITS virtual terminal (for port number p = 1–3, and F), or the
Ethernet card (port p = 5).
PROFILE Access signal profile data.
PULSE OUTnnn Pulse a relay control output (OUTnnn is a control output number).
QUIT Reduce access level to Access Level 0 (exit relay control).
RTC Display configuration of received remote synchrophasors.
SER View Sequential Events Recorder reports.
SET
c
Enter relay settings.
SHOW
c
Display relay settings.
SNS Display Sequential Events Recorder settings name strings (Fast SER).
STATUS Report or clear relay status and SEL
OGIC control equation errors.
SUMMARY View summary event reports.
TARGET Display relay elements for a row in the Relay Word table.
TEC Display time-error estimate; display or modify time-error correction value.
TEST 87L Test 87L characteristic or place channel in loopback mode.
TEST DB Test interfaces to a virtual device database.
TEST DB2 Test all communications protocols, except Fast Message.
TEST FM Display or place values in metering database (Fast Meter).
TIME Display and set the internal clock.
TIME Q Displays detailed information on the relay internal clock.
TRIGGER Initiate a data capture and record an event report.
VERSION Display the relay hardware and software configurations.
VIEW 1 View data from the communications card database.
a
See Section 15: ASCII Command Reference in the Protection Manual.
b
For help on a specific command, type HELP [command] <Enter> at an ASCII terminal communicating with the relay.
c
See the table below for SET/SHOW options.
Command
a
,
b
Description
