Date Code 20151029 SEL-411L Relay
SEL-411L Relay Command Summary
SET/SHOW Command Options
Option Setting Type Description
[S] n Group Settings 1–6 Particular application settings
B Bay Control Bay Control (Mimic) settings
A n
a
Automation Logic Block 1–10 Automation SELOGIC control equations
D DNP3 Direct Network Protocol remapping (serial port only)
F Front Panel Front-panel HMI settings
G Global Relay-wide settings
L n Protection Logic Group 1–6 Protection SEL
OGIC control equations
M Breaker Monitor Circuit breaker monitor settings
N Notes Notes settings
O Outputs Output SEL
OGIC control equations
P n Port 1–3, F, 5 Communications port settings
P 87 87L channel 87L channel configuration settings
R Report Event report and SER settings
T Alias Alias names for analog quantities and Relay Word bits
a
The -1 relay version has only one instance of automation logic settings.
