Relay Word Bits
Row List
218 AST17R–AST24R Automation sequencing Timers 17–24 reset
219 AST25R–AST32R Automation sequencing Timers 25–32 reset
Automation SELOGIC Counters
220 ACN01Q–ACN08Q Automation Counters 1–8 output
221 ACN09Q–ACN16Q Automation Counters 9–16 output
222 ACN17Q–ACN24Q Automation Counters 17–24 output
223 ACN25Q–ACN32Q Automation Counters 25–32 output
224 ACN01R–ACN08R Automation Counters 1–8 reset
225 ACN09R–ACN16R Automation Counters 9–16 reset
226 ACN17R–ACN24R Automation Counters 17–24 reset
227 ACN25R–ACN32R Automation Counters 25–32 reset
SELOGIC Error and Status Reporting
228 PUNRLBL Protection SELOGIC control equation unresolved label
228 PFRTEX Protection SEL
OGIC control equation first execution
228 MATHERR SEL
OGIC control equation math error
228 AUNRLBL Automation SEL
OGIC control equation unresolved label
228 AFRTEXP Automation SEL
OGIC control equation first execution after protection settings change,
group switch, or source switch selection
228 AFRTEXA Automation SEL
OGIC control equation first execution after automation settings change
Alarms
229 SALARM Software alarm
229 HALARM Hardware alarm
229 BADPASS Invalid password attempt alarm
229 HALARML Latched alarm for diagnostic failures
229 HALARMP Pulsed alarm for diagnostic warnings
229 HALARMA Pulse stream for unacknowledged diagnostic warnings
229 SETCHG Pulsed alarm for settings changes
229 GRPSW Pulsed alarm for group switches
230 ACCESS A user is logged-in at Access Level B or above
230 ACCESSP Pulsed alarm for logins to Access Level B or above
Under/Overvoltage
231 27TC1–27TC6 Undervoltage Elements 1–6 torque control asserted
231 271P1–272P1 Undervoltage Elements 1–2 Level 1 picked up
232 271P1T–274P1T Undervoltage Elements 1–4 Level 1 timed out
232 273P1–276P1 Undervoltage Elements 3–6 Level 1 picked up
233 271P2–276P2 Undervoltage Elements 1–6, Level 2 picked up
233 275P1T–276P1T Undervoltage Elements 5–6, Level 1 timed out
234 59TC1–59TC6 Overvoltage Elements 1–6 torque control asserted
234 591P1–592P1 Overvoltage Elements 1–2, Level 1 picked up
235 593P1–596P1 Overvoltage Elements 3–6, Level 1 picked up
235 591P1T–594P1T Overvoltage Elements 1–4 Level 1 timed out
Table 16.2 Row List of Relay Word Bits (Sheet 18 of 35)
Row Name Bit Description
