Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Row List
236 591P2–596P2 Overvoltage Elements 1–6, Level 2 picked up
236 595P1T–596P1T Overvoltage Elements 5–6 Level 1 timed out
Target Logic Bits
237 PHASE_A Indicates an A-phase fault
237 PHASE_B Indicates a B-phase fault
237 PHASE_C Indicates a C-phase fault
237 GROUND Indicates a ground fault
237 BK1BFT Indicates Circuit Breaker 1 breaker failure trip
237 BK2BFT Indicates Circuit Breaker 2 breaker failure trip
237 TRGTR Reset all active target relay words
Pushbuttons and Outputs
238 PB1–PB8 Pushbutton 1–8
239 OUT101–OUT108 Main Board Output 1–8
240 OUT201–OUT208 Optional I/O Board 1 Outputs 1–8 (if installed)
241 OUT209–OUT216 Optional I/O Board 1 Outputs 9–16 (if installed)
242 OUT301–OUT308 Optional I/O Board 2 Outputs 1–8 (if installed)
243 OUT309–OUT316 Optional I/O Board 2 Outputs 9–16 (if installed)
244 OUT401–OUT408 Optional I/O Board 3 Outputs 1–8 (if installed)
245 OUT409–OUT416 Optional I/O Board 3 Outputs 9–16 (if installed)
Pushbuttons
248 PB1_PUL–PB8_PUL Pushbuttons 1–8 pulse (on for one processing interval when button is pushed)
Pushbutton LED Bits
252 PB1_LED–PB8_LED Pushbuttons 1–8 LED
Data Reset Bits
253 RST_DEM Reset demand metering
253 RST_PDM Reset peak demand metering
253 RST_ENE Reset energy metering data
253 RSTMML Reset max/min line (SEL
OGIC control equation)
253 RSTMMB1 Reset max/min Circuit Breaker 1 (SEL
OGIC control equation)
253 RSTMMB2 Reset max/min Circuit Breaker 2 (SEL
OGIC control equation)
253 RST_BK1–RST_BK2 Reset Circuit Breaker 1–2 monitor
254 RST_BAT Reset battery monitoring (SEL
OGIC control equation)
254 RSTFLOC Reset fault locator (SEL
OGIC control equation)
254 RSTDNPE Reset DNP fault summary data (SEL
OGIC control equation)
254 RST_79C Reset recloser shot count accumulators (SEL
OGIC control equation)
254 RSTTRGT Target reset (SEL
OGIC control equation)
254 RST_HAL Reset warning alarm processing
MIRRORED BITS
255 RMB1A–RMB8A Channel A receive MIRRORED BITS 1–8
256 TMB1A–TMB8A Channel A transmit M
IRRORED BITS 1–8
257 RMB1B–RMB8B Channel B receive M
IRRORED BITS 1–8
Table 16.2 Row List of Relay Word Bits (Sheet 19 of 35)
