P.16.58
SEL-411L Relay Protection Manual Date Code 20151029
Relay Word Bits
Row List
258 TMB1B–TMB8B Channel B transmit MIRRORED BITS 1–8
259 ROKA Normal M
IRRORED BITS communications Channel A status while not in loopback mode
259 RBADA Outage too long on M
IRRORED BITS communications Channel A
259 CBADA Unavailability threshold exceeded for M
IRRORED BITS communications Channel A
259 LBOKA Normal M
IRRORED BITS communications Channel A status while in loopback mode
259 ANOKA Analog transfer OK on M
IRRORED BITS communications Channel A
259 DOKA Normal M
IRRORED BITS communications Channel A status
260 ROKB Normal M
IRRORED BITS communications Channel B status while not in loopback mode
260 RBADB Outage too long on M
IRRORED BITS communications Channel B
260 CBADB Unavailability threshold exceeded for M
IRRORED BITS communications Channel B
260 LBOKB Normal M
IRRORED BITS communications Channel B status while in loopback mode
260 ANOKB Analog transfer OK on M
IRRORED BITS communications Channel B
260 DOKB Normal M
IRRORED BITS communications Channel B status
Virtual Bits
264 VB249–VB256 Virtual Bits 249–256
265 VB241–VB248 Virtual Bits 241–248
266 VB233–VB240 Virtual Bits 233–240
267 VB225–VB232 Virtual Bits 225–232
268 VB217–VB224 Virtual Bits 217–224
269 VB209–VB216 Virtual Bits 209–216
270 VB201–VB208 Virtual Bits 201–208
271 VB193–VB200 Virtual Bits 193–200
272 VB185–VB192 Virtual Bits 185–192
273 VB177–VB184 Virtual Bits 177–184
274 VB169–VB176 Virtual Bits 169–176
275 VB161–VB168 Virtual Bits 161–168
276 VB153–VB160 Virtual Bits 153–160
277 VB145–VB152 Virtual Bits 145–152
278 VB137–VB144 Virtual Bits 137–144
279 VB129–VB136 Virtual Bits 129–136
280 VB121–VB128 Virtual Bits 121–128
281 VB113–VB120 Virtual Bits 113–120
282 VB105–VB112 Virtual Bits 105–112
283 VB097–VB104 Virtual Bits 097–104
284 VB089–VB096 Virtual Bits 089–096
285 VB081–VB088 Virtual Bits 081–088
286 VB073–VB080 Virtual Bits 073–080
287 VB065–VB072 Virtual Bits 065–072
288 VB057–VB064 Virtual Bits 057–064
289 VB049–VB056 Virtual Bits 049–056
290 VB041–VB048 Virtual Bits 041–048
Table 16.2 Row List of Relay Word Bits (Sheet 20 of 35)
Row Name Bit Description
