Relay Word Bits
Row List
291 VB033–VB040 Virtual Bits 033–040
292 VB025–VB032 Virtual Bits 025–032
293 VB017–VB024 Virtual Bits 017–024
294 VB009–VB016 Virtual Bits 009–016
295 VB001–VB008 Virtual Bits 001–008
Full Cycle Mho & Quad Ground Distance
296 XAG1F, XBG1F, XCG1F Zone 1 filtered quad A-phase, B-phase, C-phase-to-ground element
296 MAG1F, MBG1F, MCG1F Zone 1 filtered mho A-phase, B-phase, C-phase-to-ground element
296 MBG2F Zone 2 filtered B-phase-to-ground mho element asserted
296 MAG2F Zone 2 filtered mho A-phase-to-ground element
297 XAG2F, XBG2F, XCG2F Zone 2 filtered quad A-phase, B-phase, C-phase-to-ground element
297 MCG2F Zone 2 filtered mho C-phase-to-ground element
297 XAG3F Zone 3 filtered quad A-phase-to-ground element
297 MAG3F, MBG3F, MCG3F Zone 3 filtered mho A-phase, B-phase, C-phase-to-ground element
298 XBG3F, XCG3F Zone 3 filtered quad B- C-phase-to-ground element
298 XAG4F, XBG4F, XCG4F Zone 4 filtered quad A-phase, B-phase, C-phase-to-ground element
298 MAG4F, MBG4F, MCG4F Zone 4 filtered mho A-phase, B-phase, C-phase-to-ground element
299 XAG5F, XBG5F, XCG5F Zone 5 filtered quad A-phase, B-phase, C-phase-to-ground element
299 MAG5F, MBG5F, MCG5F Zone 5 filtered mho A-phase, B-phase, C-phase-to-ground element
300 XCA1F Zone 1 filtered quad CA phase element
300 XBC1F Zone 1 filtered quad BC phase element
300 XAB1F Zone 1 filtered quad AB phase element
300 MCA1F Zone 1 filtered mho CA phase element
300 MBC1F Zone 1 filtered mho BC phase element
300 MAB1F Zone 1 filtered mho AB phase element
300 MBC2F Zone 2 filtered mho BC phase element
300 MAB2F Zone 2 filtered mho AB phase element
301 XCA2F Zone 2 filtered quad CA phase element
301 XBC2F Zone 2 filtered quad BC phase element
301 XAB2F Zone 2 filtered quad AB phase element
301 MCA2F Zone 2 filtered mho CA phase element
301 XAB3F Zone 3 filtered quad AB phase element
301 MCA3F Zone 3 filtered mho CA phase element
301 MBC3F Zone 3 filtered mho BC phase element
301 MAB3F Zone 3 filtered mho AB phase element
302 XCA3F Zone 3 filtered quad CA phase element
302 XBC3F Zone 3 filtered quad BC phase element
302 XCA4F Zone 4 filtered quad CA phase element
302 XBC4F Zone 4 filtered quad BC phase element
302 XAB4F Zone 4 filtered quad AB phase element
302 MCA4F Zone 4 filtered mho CA phase element
