P.16.68
SEL-411L Relay Protection Manual Date Code 20151029
Relay Word Bits
Row List
379 522CLSM Breaker 2 closed
379 522_ALM Breaker 2 status alarm
379 523CLSM Breaker 3 closed
379 523_ALM Breaker 3 status alarm
380 89CBL02 Disconnect 02 close block
380 89OSI02 Disconnect 02 open seal-in timer timed out
380 89CSI02 Disconnect 02 close seal-in timer timed out
380 89OIR02 Disconnect 02 open immobility timer reset
380 89CIR02 Disconnect 02 close immobility timer reset
380 89OBL02 Disconnect 02 open block
380 89ORS02 Disconnect 02 open reset
380 89CRS02 Disconnect 02 close reset
381 89OIM02 Disconnect 02 open immobility timer timed out
381 89CIM02 Disconnect 02 close immobility timer timed out
381 89CBL03 Disconnect 03 close block
381 89OSI03 Disconnect 03 open seal-in timer timed out
381 89CSI03 Disconnect 03 close seal-in timer timed out
381 89OIR03 Disconnect 03 open immobility timer reset
382 89CIR03 Disconnect 03 close immobility timer reset
382 89OBL03 Disconnect 03 open block
382 89ORS03 Disconnect 03 open reset
382 89CRS03 Disconnect 03 close reset
382 89OIM03 Disconnect 03 open immobility timer timed out
382 89CIM03 Disconnect 03 close immobility timer timed out
383 89CBL04 Disconnect 04 close block
383 89OSI04 Disconnect 04 open seal-in timer timed out
383 89CSI04 Disconnect 04 close seal-in timer timed out
383 89OIR04 Disconnect 04 open immobility timer reset
383 89CIR04 Disconnect 04 close immobility timer reset
383 89OBL04 Disconnect 04 open block
383 89ORS04 Disconnect 04 open reset
383 89CRS04 Disconnect 04 close reset
384 89OIM04 Disconnect 04 open immobility timer timed out
384 89CIM04 Disconnect 04 close immobility timer timed out
384 89CBL05 Disconnect 05 close block
384 89OSI05 Disconnect 05 open seal-in timer timed out
384 89CSI05 Disconnect 05 close seal-in timer timed out
384 89OIR05 Disconnect 05 open immobility timer reset
385 89CIR05 Disconnect 05 close immobility timer reset
385 89OBL05 Disconnect 05 open block
385 89ORS05 Disconnect 05 open reset
Table 16.2 Row List of Relay Word Bits (Sheet 30 of 35)
Row Name Bit Description
