Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Row List
374 89OPE07 Disconnect open 7 output
374 89CLS07 Disconnect close 7 output
374 89OCN07 Open Disconnect 7
374 89CCN07 Close Disconnect 7
375 89OC08 ASCII open Disconnect 8 command
375 89CC08 ASCII close Disconnect 8 command
375 89OCM08 Mimic Disconnect 8 open control
375 89CCM08 Mimic Disconnect 8 close control
375 89OPE08 Disconnect open 8 output
375 89CLS08 Disconnect close 8 output
375 89OCN08 Open Disconnect 8
375 89CCN08 Close Disconnect 8
376 89OC09 ASCII open Disconnect 9 command
376 89CC09 ASCII close Disconnect 9 command
376 89OCM09 Mimic Disconnect 9 open control
376 89CCM09 Mimic Disconnect 9 close control
376 89OPE09 Disconnect open 9 output
376 89CLS09 Disconnect close 9 output
376 89OCN09 Open Disconnect 9
376 89CCN09 Close Disconnect 9
377 89OC10 ASCII open Disconnect 10 command
377 89CC10 ASCII close Disconnect 10 command
377 89OCM10 Mimic Disconnect 10 open control
377 89CCM10 Mimic Disconnect 10 close control
377 89OPE10 Disconnect open 10 output
377 89CLS10 Disconnect close 10 output
377 89OCN10 Open Disconnect 10
377 89CCN10 Close Disconnect 10
Bay Control Disconnect Timers and Breaker Status
378 89CBL01 Disconnect 01 close block
378 89OSI01 Disconnect 01 open seal-in timer timed out
378 89CSI01 Disconnect 01 close seal-in timer timed out
378 89OIR01 Disconnect 01 open immobility timer reset
378 89CIR01 Disconnect 01 close immobility timer reset
378 89OBL01 Disconnect 01 open block
378 89ORS01 Disconnect 01 open reset
378 89CRS01 Disconnect 01 close reset
379 89OIM01 Disconnect 01 open immobility timer timed out
379 89CIM01 Disconnect 01 close immobility timer timed out
379 521CLSM Breaker 1 closed
379 521_ALM Breaker 1 status alarm
Table 16.2 Row List of Relay Word Bits (Sheet 29 of 35)
Row Name Bit Description
