P.16.66
SEL-411L Relay Protection Manual Date Code 20151029
Relay Word Bits
Row List
369 89CCM02 Mimic Disconnect 2 close control
369 89OPE02 Disconnect open 2 output
369 89CLS02 Disconnect close 2 output
369 89OCN02 Open Disconnect 2
369 89CCN02 Close Disconnect 2
370 89OC03 ASCII open Disconnect 3 command
370 89CC03 ASCII close Disconnect 3 command
370 89OCM03 Mimic Disconnect 3 open control
370 89CCM03 Mimic Disconnect 3 close control
370 89OPE03 Disconnect open 3 output
370 89CLS03 Disconnect close 3 output
370 89OCN03 Open Disconnect 3
370 89CCN03 Close Disconnect 3
371 89OC04 ASCII open Disconnect 4 command
371 89CC04 ASCII close Disconnect 4 command
371 89OCM04 Mimic Disconnect 4 open control
371 89CCM04 Mimic Disconnect 4 close control
371 89OPE04 Disconnect open 4 output
371 89CLS04 Disconnect close 4 output
371 89OCN04 Open Disconnect 4
371 89CCN04 Close Disconnect 4
372 89OC05 ASCII open Disconnect 5 command
372 89CC05 ASCII close Disconnect 5 command
372 89OCM05 Mimic Disconnect 5 open control
372 89CCM05 Mimic Disconnect 5 close control
372 89OPE05 Disconnect open 5 output
372 89CLS05 Disconnect close 5 output
372 89OCN05 Open Disconnect 5
372 89CCN05 Close Disconnect 5
373 89OC06 ASCII open Disconnect 6 command
373 89CC06 ASCII close Disconnect 6 command
373 89OCM06 Mimic Disconnect 6 open control
373 89CCM06 Mimic Disconnect 6 close control
373 89OPE06 Disconnect open 6 output
373 89CLS06 Disconnect close 6 output
373 89OCN06 Open Disconnect 6
373 89CCN06 Close Disconnect 6
374 89OC07 ASCII open Disconnect 7 command
374 89CC07 ASCII close Disconnect 7 command
374 89OCM07 Mimic Disconnect 7 open control
374 89CCM07 Mimic Disconnect 7 close control
Table 16.2 Row List of Relay Word Bits (Sheet 28 of 35)
Row Name Bit Description
