P.16.65
Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Row List
361 89OIP06 Disconnect 6 operation in progress
361 89AL06 Disconnect 6 alarm
362 89AM07 Disconnect 7 N/O auxiliary contact
362 89BM07 Disconnect 7 N/C auxiliary contact
362 89CL07 Disconnect 7 closed
362 89OPN07 Disconnect 7 open
362 89OIP07 Disconnect 7 operation in progress
362 89AL07 Disconnect 7 alarm
363 89AM08 Disconnect 8 N/O auxiliary contact
363 89BM08 Disconnect 8 N/C auxiliary contact
363 89CL08 Disconnect 8 closed
363 89OPN08 Disconnect 8 open
363 89OIP08 Disconnect 8 operation in progress
363 89AL08 Disconnect 8 alarm
364 89AM09 Disconnect 9 N/O auxiliary contact
364 89BM09 Disconnect 9 N/C auxiliary contact
364 89CL09 Disconnect 9 closed
364 89OPN09 Disconnect 9 open
364 89OIP09 Disconnect 9 operation in progress
364 89AL09 Disconnect 9 alarm
365 89AM10 Disconnect 10 N/O auxiliary contact
365 89BM10 Disconnect 10 N/C auxiliary contact
365 89CL10 Disconnect 10 closed
365 89OPN10 Disconnect 10 open
365 89OIP10 Disconnect 10 operation in progress
365 89AL10 Disconnect 10 alarm
Bay Control Disconnect Buszone Compliant
366 89CLB01–89CLB08 Disconnect 1–8 buszone protection
367 89CLB09–89CLB10 Disconnect 9–10 buszone protection
Bay Control Disconnect Control
368 89OC01 ASCII open Disconnect 1 command
368 89CC01 ASCII close Disconnect 1 command
368 89OCM01 Mimic Disconnect 1 open control
368 89CCM01 Mimic Disconnect 1 close control
368 89OPE01 Disconnect open 1 output
368 89CLS01 Disconnect close 1 output
368 89OCN01 Open Disconnect 1
368 89CCN01 Close Disconnect 1
369 89OC02 ASCII open Disconnect 2 command
369 89CC02 ASCII close Disconnect 2 command
369 89OCM02 Mimic Disconnect 2 open control
Table 16.2 Row List of Relay Word Bits (Sheet 27 of 35)
Row Name Bit Description
