P.16.64
SEL-411L Relay Protection Manual Date Code 20151029
Relay Word Bits
Row List
353 FOP3_09–FOP3_16 Fast-operate output control bits for Port 3, Bits 09–16
354 FOP3_17–FOP3_24 Fast-operate output control bits for Port 3, Bits 17–24
355 FOP3_25–FOP3_32 Fast-operate output control bits for Port 3, Bits 25–32
Bay Control Disconnect Status
356 89AM01 Disconnect 1 N/O auxiliary contact
356 89BM01 Disconnect 1 N/C Auxiliary contact
356 89CL01 Disconnect 1 closed
356 89OPN01 Disconnect 1 open
356 89OIP01 Disconnect 1 operation in progress
356 89AL01 Disconnect 1 alarm
356 89AL Any disconnect alarm
357 89AM02 Disconnect 2 N/O auxiliary contact
357 89BM02 Disconnect 2 N/C auxiliary contact
357 89CL02 Disconnect 2 closed
357 89OPN02 Disconnect 2 open
357 89OIP02 Disconnect 2 operation in progress
357 89AL02 Disconnect 2 alarm
357 89OIP Any disconnect operation in progress
358 89AM03 Disconnect 3 N/O auxiliary contact
358 89BM03 Disconnect 3 N/C auxiliary contact
358 89CL03 Disconnect 3 closed
358 89OPN03 Disconnect 3 open
358 89OIP03 Disconnect 3 operation in progress
358 89AL03 Disconnect 3 alarm
358 LOCAL Local front-panel control
359 89AM04 Disconnect 4 N/O auxiliary contact
359 89BM04 Disconnect 4 N/C auxiliary contact
359 89CL04 Disconnect 4 closed
359 89OPN04 Disconnect 4 open
359 89OIP04 Disconnect 4 operation in progress
359 89AL04 Disconnect 4 alarm
360 89AM05 Disconnect 5 N/O auxiliary contact
360 89BM05 Disconnect 5 N/C auxiliary contact
360 89CL05 Disconnect 5 closed
360 89OPN05 Disconnect 5 open
360 89OIP05 Disconnect 5 operation in progress
360 89AL05 Disconnect 5 alarm
361 89AM06 Disconnect 6 N/O auxiliary contact
361 89BM06 Disconnect 6 N/C auxiliary contact
361 89CL06 Disconnect 6 closed
361 89OPN06 Disconnect 6 open
Table 16.2 Row List of Relay Word Bits (Sheet 26 of 35)
Row Name Bit Description
