P.16.63
Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Row List
323 TSNTPP Relay time is based on SNTP using primary server
323 TSNTPB Relay time is based on SNTP using backup server
Pushbuttons, Pushbutton LEDs, and Target LEDs for new HMI
324 TLED_17–TLED_24 Target LEDs 17–24
325 PB9–PB12 Pushbuttons 9–12
325 PB_TRIP Auxiliary TRIP pushbutton
325 PB_CLSE Auxiliary CLOSE pushbutton
326 PB9_LED–PB12LED Pushbuttons 9–12 LED
326 PB9_PUL–PB12PUL Pushbuttons 9–12 pulse (on for one processing interval when button is pushed)
Local Control Bits Supervision
327 LB_SP01–LB_SP08 Local Bits 01–08 supervision (SELOGIC equation)
328 LB_SP09–LB_SP16 Local Bits 09–16 supervision (SEL
OGIC equation)
329 LB_SP17–LB_SP24 Local Bits 17–24 supervision (SEL
OGIC equation)
330 LB_SP25–LB_SP32 Local Bits 25–32 supervision (SEL
OGIC equation)
Local Control Bits Status
331 LB_DP01–LB_DP08 Local Bits 01–08 status display (SELOGIC equation)
332 LB_DP09–LB_DP16 Local Bits 09–16 status display (SEL
OGIC equation)
333 LB_DP17–LB_DP24 Local Bits 17–24 status display (SEL
OGIC equation)
334 LB_DP25–LB_DP32 Local Bits 25–32 status display (SEL
OGIC equation)
Synchrophasor Configuration Error
335 SPCER1–SPCER3 Synchrophasor Configuration Error on Port 1–3
335 SPCERF Synchrophasor Configuration Error on Port F
RTC Remote Digital Status
336 RTCAD01–RTCAD08 RTC remote data bits, Channel A, Bits 01–08
337 RTCAD09–RTCAD16 RTC remote data bits, Channel A, Bits 09–16
338 RTCBD01–RTCBD08 RTC remote data bits, Channel B, Bits 01–08
339 RTCBD09–RTCBD16 RTC remote data bits, Channel B, Bits 09–16
Fast Operate Transmit Bits
340 FOPF_01–FOPF_08 Fast-operate output control bits for Port F, Bits 01–08
341 FOPF_09–FOPF_16 Fast-operate output control bits for Port F, Bits 09–16
342 FOPF_17–FOPF_24 Fast-operate output control bits for Port F, Bits 17–24
343 FOPF_25–FOPF_32 Fast-operate output control bits for Port F, Bits 25–32
344 FOP1_01–FOP1_08 Fast-operate output control bits for Port 1, Bits 01–08
345 FOP1_09–FOP1_16 Fast-operate output control bits for Port 1, Bits 09–16
346 FOP1_17–FOP1_24 Fast-operate output control bits for Port 1, Bits 17–24
347 FOP1_25–FOP1_32 Fast-operate output control bits for Port 1, Bits 25–32
348 FOP2_01–FOP2_08 Fast-operate output control bits for Port 2, Bits 01–08
349 FOP2_09–FOP2_16 Fast-operate output control bits for Port 2, Bits 09–16
350 FOP2_17–FOP2_24 Fast-operate output control bits for Port 2, Bits 17–24
351 FOP2_25–FOP2_32 Fast-operate output control bits for Port 2, Bits 25–32
352 FOP3_01–FOP3_08 Fast-operate output control bits for Port 3, Bits 01–08
Table 16.2 Row List of Relay Word Bits (Sheet 25 of 35)
Row Name Bit Description
