P.16.62
SEL-411L Relay Protection Manual Date Code 20151029
Relay Word Bits
Row List
Time and Date Management and Frequency Calculation
316 FREQOK Assert if relay is estimating frequency
316 FREQFZ Assert if relay is not calculating frequency
Ethernet Switch
317 LINK5A–LINK5D Link status of Port 5A–5D connection
317 LNKFAIL Link status of the active port
317 LNKFL2 Set to 1 if link status of active 87L or sampled value port is down
318 P5ASEL–P5DSEL Port 5A–5D active/inactive
Settings Group Bits
319 SG1–SG6 Setting Groups 1–6 active
319 CHSG Settings group change
IRIG-B Control Bits, Time-Error Calculation Bits and SNTP Bits
320 YEAR80 IRIG-B year information, binary-coded decimal, add 80 if asserted
320 YEAR40 IRIG-B year information, binary-coded decimal, add 40 if asserted
320 YEAR20 IRIG-B year information, binary-coded decimal, add 20 if asserted
320 YEAR10 IRIG-B year information, binary-coded decimal, add 10 if asserted
320 YEAR8 IRIG-B year information, binary-coded decimal, add 8 if asserted
320 YEAR4 IRIG-B year information, binary-coded decimal, add 4 if asserted
320 YEAR2 IRIG-B year information, binary-coded decimal, add 2 if asserted
320 YEAR1 IRIG-B year information, binary-coded decimal, add 1 if asserted
321 TUTCH Offset half-hour from UTC time, binary, add 0.5 if asserted
321 TUTC8 Offset hours from UTC time, binary, add 8 if asserted
321 TUTC4 Offset hours from UTC time, binary, add 4 if asserted
321 TUTC2 Offset hours from UTC time, binary, add 2 if asserted
321 TUTC1 Offset hours from UTC time, binary, add 1 if asserted
321 TUTCS Offset hours sign from UTC time, subtract the UTC offset if TUTCS is asserted, add otherwise
322 DST Daylight-saving time
322 DSTP Daylight-saving time pending
322 LPSEC Direction of the upcoming leap second. During the time that LPSECP is asserted, if LPSEC is
asserted, the upcoming leap second is deleted; otherwise, the leap second is added.
322 LPSECP Leap second pending
322 TQUAL8 Time quality, binary, add 8 when asserted
322 TQUAL4 Time quality, binary, add 4 when asserted
322 TQUAL2 Time quality, binary, add 2 when asserted
322 TQUAL1 Time quality, binary, add 1 when asserted
323 LOADTE Load TECORR Factor (SEL
OGIC Equation). When a rising-edge is detected, the accumu-
lated time-error value TE is loaded with the TECORR factor (preload value).
323 STALLTE Stall time-error calculation (SEL
OGIC equation). When asserted, the time-error calcula-
tion is stalled, or frozen.
323 PLDTE Asserts for approximately 1.5 cycles when the TEC command is used to load a new
time-error correction factor (preload value) into the TECORR analog quantity.
Table 16.2 Row List of Relay Word Bits (Sheet 24 of 35)
Row Name Bit Description
