P.16.61
Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Row List
309 XBC1H
a
High-speed Zone 1 high-speed quad BC phase element
309 XAB1H
a
High-speed Zone 1 high-speed quad AB phase element
309 XCA2H
a
High-speed Zone 2 high-speed quad CA phase element
309 XBC2H
a
High-speed Zone 2 high-speed quad BC phase element
309 XAB2H
a
High-speed Zone 2 high-speed quad AB phase element
309 XAB3H
a
High-speed Zone 3 high-speed quad AB phase element
309 MCA3H
a
High-speed Zone 3 mho CA phase element
310 XCA3H
a
High-speed Zone 3 high-speed quad CA phase element
310 XBC3H
a
High-speed Zone 3 high-speed quad BC phase element
Synchrophasor SELOGIC Equations/RTC Synchrophasor Status Bits
311 PMTEST Synchrophasor test mode
311 PMTRIG Trigger (SEL
OGIC control equation)
311 TREA1–TREA4 Trigger Reason Bit 1–4 (SEL
OGIC Equation)
311 FROKPM Synchrophasor frequency
312 EVELOCK Lock DNP events
312 RTCSEQB RTC configuration complete, Channel B
312 RTCSEQA RTC configuration complete, Channel A
312 RTCCFGB RTC data in sequence, Channel B
312 RTCCFGA RTC data in sequence, Channel A
313 FSERP5 Fast SER enabled for Serial Port 5
313 RTCDLYB RTC delay exceeded, Channel B
313 RTCDLYA RTC delay exceeded, Channel A
313 RTCROK Valid aligned RTC data available on all enabled channels
313 RTCROKB Valid aligned RTC data available on Channel B
313 RTCROKA Valid aligned RTC data available on Channel A
313 RTCENB Valid remote synchrophasors received on Channel B
313 RTCENA Valid remote synchrophasors received on Channel A
Fast SER Enable Bits and Source Selection Elements
314 FSERP1–FSERP3 Fast SER enabled for Serial Ports 1–3
314 FSERPF Fast SER enabled for Serial Port F
314 ALTI Alternate current source (SELOGIC control equation)
314 ALTV Alternate voltage source (SEL
OGIC control equation)
314 ALTS2 Alternate synchronism source for Circuit Breaker 2
314 DELAY Local current and voltage source delay logic
Testing Bits and Signal Profiling
315 TESTDB2 Communications card database test Bit 2
315 TESTDB Communications card database test bit
315 TESTFM Fast meter test bit
315 TESTPUL Pulse test bit
315 LPHDSIM IEC 61850 logical node for physical device simulation
315 SPEN Signal profiling enabled
Table 16.2 Row List of Relay Word Bits (Sheet 23 of 35)
Row Name Bit Description
