System configuration controller (SYSCFG) RM0367

264/1043 RM0367 Rev 7

Refer to Section 2.2 on page 58 for the register boundary addresses.

0x10

SYSCFG_

EXTICR3

Res.

EXTI11[3:0] EXTI10[3:0] EXTI9[3:0] EXTI8[3:0]

Reset value 0000000000000000

0x14

SYSCFG_

EXTICR4

Res.

EXTI15[3:0] EXTI14[3:0] EXTI13[3:0] EXTI12[3:0]

Reset value 0000000000000000

0x18 COMP1_CTRL

Refer to Section 16: Comparator (COMP)

0x1C COMP2_CTRL

0x20

SYSCFG_CFGR3

REF_LOCK

VREFINT_RDYF

Res.

ENREF_HSI48

ENBUF_VREFINT_COMP2

Res.

ENBUF_SENSOR_ADC

ENBUF_VREFINT_ADC

Res.

SEL_VREF_OUT

Res.

EN_VREFINT

Reset value 00 00 00 00 0

Table 49. SYSCFG register map and reset values (continued)

Offset Register
