ST STM32L0x3 User Manual

RM0367
60/1043 RM0367 Rev 7
The following table gives the boundary addresses of the peripherals available in the
devices.
Table 3. STM32L0x3 peripheral register boundary addresses
(1)
Bus Boundary address Size (bytes) Peripheral Peripheral register map
IOPORT
0X5000 1C00 - 0X5000 1FFF 1K GPIOH
Section 9.4.12: GPIO register
map
0X5000 1400 - 0X5000 1BFF 2 K Reserved -
0X5000 1000 - 0X5000 13FF 1K GPIOE
Section 9.4.12: GPIO register
map
0X5000 0C00 - 0X5000 0FFF 1K GPIOD
Section 9.4.12: GPIO register
map
0X5000 0800 - 0X5000 0BFF 1K GPIO C
Section 9.4.12: GPIO register
map
0X5000 0400 - 0X5000 07FF 1K GPIOB
Section 9.4.12: GPIO register
map
0X5000 0000 - 0X5000 03FF 1K GPIOA
Section 9.4.12: GPIO register
map
AHB
0X4002 6400 - 0X4002 FFFF 49 K Reserved -
0X4002 6000 - 0X4002 63FF 1 K
AES (Cat 3 and
5 with AES
only)
Section 19.7.13: AES register
map
0X4002 5400 - 0X4002 5FFF 3 K Reserved -
0X4002 5000 - 0X4002 53FF 1 K RNG
Section 20.7.4: RNG register
map
0X4002 4400 - 0X4002 4FFF 3 K Reserved -
0X4002 4000 - 0X4002 43FF 1 K TSC
Section 18.6.11: TSC register
map
0X4002 3400 - 0X4002 3FFF 3 K Reserved -
0X4002 3000 - 0X4002 33FF 1 K CRC Section 4.4.6: CRC register map
0X4002 2400 - 0X4002 2FFF 3 K Reserved -
0X4002 2000 - 0X4002 23FF 1 K FLASH
Section 3.7.11: Flash register
map
0X4002 1400 - 0X4002 1FFF 3 K Reserved -
0X4002 1000 - 0X4002 13FF 1 K RCC
Section 7.3.22: RCC register
map
0X4002 0400 - 0X4002 0FFF 3 K Reserved -
0X4002 0000 - 0X4002 03FF 1 K DMA1
Section 11.6.8: DMA register
map
