RM0367 Rev 7 61/1043
RM0367
65
APB2
0X4001 5C00 - 0X4001 FFFF 42 K Reserved -
0X4001 5800 - 0X4001 5BFF 1 K DBG
Section 33.10: DBG register
map
0X4001 3C00 - 0X4001 57FF 7 K Reserved -
0X4001 3800 - 0X4001 3BFF 1 K USART1
Section 29.8.12: USART
register map
0X4001 3400 - 0X4001 37FF 1 K Reserved -
0X4001 3000 - 0X4001 33FF 1 K SPI1
Section 31.7.10: SPI register
map
0X4001 2800 - 0X4001 2FFF 2 K Reserved -
0X4001 2400 - 0X4001 27FF 1 K ADC1
Section 14.13: ADC register
map
0X4001 2000 - 0X4001 23FF 1 K Reserved -
0X4001 1C00 - 0X4001 1FFF 1 K Firewall
Section 5.4.8: Firewall register
map
0X4001 1800 - 0X4001 1BFF 1 K Reserved -
0X4001 1400 - 0X4001 17FF 1 K TIM22
Section 22.4.16: TIM21/22
register map
0X4001 0C000 - 0X4001 13FF 2 K Reserved -
0X4001 0800 - 0X4001 0BFF 1 K TIM21
Section 22.4.16: TIM21/22
register map
0X4001 0400 - 0X4001 07FF 1 K EXTI
Section 13.5.7: EXTI register
map
0X4001 0000 - 0X4001 03FF 1 K
SYSCFG,
COMP
Section 10.2.8: SYSCFG
register map, Section 16.5.3:
COMP register map
Table 3. STM32L0x3 peripheral register boundary addresses
(1)
(continued)
Bus Boundary address Size (bytes) Peripheral Peripheral register map
