RM0367 Flash program memory and data EEPROM (FLASH)
122
Table 7. Flash memory and data EEPROM remapping
(192 Kbyte category 5 devices)
NVM
Description
NVM addresses Remapped addresses
MEM_MODE = 0,
BOOT0= 0 and
UFB = 0
MEM_MODE = 0,
BOOT0= 0 and
UFB = 1
MEM_MODE = 0,
BOOT0= 0 and
UFB = 0
MEM_MODE = 0,
BOOT0= 0 and
UFB = 1
Flash
program
memory
Bank 1
0x0800 0000 -
0x0801 7FFF
0x0801 8000 -
0x0802 FFFF
0x0000 0000 -
0x0001 7FFF
0x0001 8000 -
0x0002 FFFF
Bank 2
0x0801 8000 -
0x0802 FFFF
0x08000 0000 -
0x0801 7FFF
0x0001 8000 -
0x0002 FFFF
0x0000 0000 -
0x0001 7FFF
Data
EEPROM
Bank 1
0x0808 0000 -
0x0808 0BFF
0x0808 0C00 -
0x0808 17FF
0x0008 0000 -
0x0008 0BFF
0x0008 0C00 -
0x0008 17FF
Bank 2
0x0808 0C00 -
0x0808 17FF
0x0808 0000 -
0x0008 0BFF
0x0008 0C00 -
0x0008 17FF
0x0008 0000 -
0x0008 0BFF
Table 8. NVM organization for UFB = 0 (128 Kbyte category 5 devices)
NVM NVM addresses Size (bytes) Name Description
Flash program
memory
0x0800 0000 - 0x0800 007F 128 bytes Page 0
sector 0
Bank 1
0x0800 0080 - 0x0800 00FF 128 bytes Page 1
---
0x0800 0F80 - 0x0800 0FFF 128 bytes Page 31
.
.
.
.
.
.
.
.
.
.
.
.
0x0800 7000 - 0x0800 707F 128 bytes Page 224
sector 7
0x0800 7080 - 0x0800 70FF 128 bytes Page 225
---
0x0800 7F80 - 0x0800 7FFF 128 bytes Page 255
.
.
.
.
.
.
.
.
.
.
.
.
0x0800 FF80- 0x0800 FFFF 128 bytes Page 511 sector 15
0x0801 0000 - 0x0801 007F 128 bytes Page 512 sector 16
Bank 2
.
.
.
.
.
.
.
.
.
.
.
.
0x0801 F000 - 0x0801 F07F Page 992
sector 31
---
0x0801 FF80 - 0x0801 FFFF 128 bytes Page 1023
Data EEPROM
0x0808 0000 - 0x0808 0BFF
6Kbytes
- Data EEPROM Bank 1
0x0808 0C00 - 0x0808 17FF - Data EEPROM Bank 2
