Analog-to-digital converter (ADC) RM0367
348/1043 RM0367 Rev 7
14.12.7 ADC watchdog threshold register (ADC_TR)
Address offset: 0x20
Reset value: 0x0FFF 0000
14.12.8 ADC channel selection register (ADC_CHSELR)
Address offset: 0x28
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. HT[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
Res. Res. Res. Res. LT[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:28 Reserved, must be kept at reset value.
Bits 27:16 HT[11:0]: Analog watchdog higher threshold
These bits are written by software to define the higher threshold for the analog watchdog. Refer to
Section 14.7: Analog window watchdog (AWDEN, AWDSGL, AWDCH, ADC_TR) on page 326
Note: The software is allowed to write this bit only when ADSTART = 0 (which ensures that no
conversion is ongoing).
Bits 15:12 Reserved, must be kept at reset value.
Bits 11:0 LT[11:0]: Analog watchdog lower threshold
These bits are written by software to define the lower threshold for the analog watchdog.
Refer to Section 14.7: Analog window watchdog (AWDEN, AWDSGL, AWDCH, ADC_TR) on
page 326.
Note: The software is allowed to write this bit only when ADSTART = 0 (which ensures that no
conversion is ongoing).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
CHSEL
18
CHSEL
17
CHSEL
16
rw rw rw
1514131211109876543210
CHSEL
15
CHSEL
14
CHSEL
13
CHSEL
12
CHSEL
11
CHSEL
10
CHSEL
9
CHSEL
8
CHSEL
7
CHSEL
6
CHSEL
5
CHSEL
4
CHSEL
3
CHSEL
2
CHSEL
1
CHSEL
0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
