RM0367 Rev 7 963/1043
RM0367 Debug support (DBG)
970
33.6 Core debug
Core debug is accessed through the core debug registers. Debug access to these registers
is by means of the debug access port. It consists of four registers:
These registers are not reset by a system reset. They are only reset by a power-on reset.
Refer to the Cortex
®
-M0+ TRM for further details.
To Halt on reset, it is necessary to:
• enable the bit0 (VC_CORRESET) of the Debug and Exception Monitor Control
Register
• enable the bit0 (C_DEBUGEN) of the Debug Halting Control and Status Register
33.7 BPU (Break Point Unit)
The Cortex
®
-M0+ BPU implementation provides four breakpoint registers. The BPU is a
subset of the Flash Patch and Breakpoint (FPB) block available in Armv7-M (Cortex
®
-M3
and Cortex
®
-M4).
33.7.1 BPU functionality
The processor breakpoints implement PC based breakpoint functionality.
Refer the Armv6-M Arm
®
and the Arm
®
CoreSight Components Technical Reference
Manual for more information about the BPU CoreSight identification registers, and their
addresses and access types.
Table 179. Core debug registers
Register Description
DHCSR
The 32-bit Debug Halting Control and Status Register
This provides status information about the state of the processor enable core debug
halt and step the processor
DCRSR
The 17-bit Debug Core Register Selector Register:
This selects the processor register to transfer data to or from.
DCRDR
The 32-bit Debug Core Register Data Register:
This holds data for reading and writing registers to and from the processor selected
by the DCRSR (Selector) register.
DEMCR
The 32-bit Debug Exception and Monitor Control Register:
This provides Vector Catching and Debug Monitor Control.
