Inter-integrated circuit (I2C) interface RM0367

742/1043 RM0367 Rev 7

Figure 241. Bus transfer diagrams for SMBus master receiver

MS19872V2

Example SMBus master receiver 2 bytes + PEC, automatic end mode (STOP)

Address

INIT: program Slave address, program NBYTES = 3, AUTOEND=1, set PECBYTE, set START

EV1: RXNE ISR: rd data1

EV2: RXNE ISR: rd data2

EV3: RXNE ISR: rd PEC

data1

RXNE RXNE

data2

NBYTES

legend:

transmission

reception

SCL stretch

3VE1VE

xx 3

INIT

Example SMBus master receiver 2 bytes + PEC, software end mode (RESTART)

Address

INIT: program Slave address, program NBYTES = 3, AUTOEND=0, set PECBYTE, set START

EV1: RXNE ISR: rd data1

EV2: RXNE ISR: rd data2

EV3: RXNE ISR: read PEC

EV4: TC ISR: program Slave address, program NBYTES = N, set START

data1

RXNE RXNE

data2

NBYTES

Restart

legend:

transmission

reception

SCL stretch

EV1 EV2

INIT

Address

PEC

RXNE

EV2

PEC

RXNE

EV3

EV4
