ST STM32L0x3 User Manual

RM0367 Rev 7 347/1043
RM0367 Analog-to-digital converter (ADC)
352
14.12.6 ADC sampling time register (ADC_SMPR)
Address offset: 0x14
Reset value: 0x0000 0000
Bits 4:2 OVSR[2:0]: Oversampling ratio
This bit filed defines the number of oversampling ratio.
000: 2x
001: 4x
010: 8x
011: 16x
100: 32x
101: 64x
110: 128x
111: 256x
Note: The software is allowed to write this bit only when ADSTART = 0 (which ensures that no
conversion is ongoing).
Bit 1 Reserved, must be kept at reset value.
Bit 0 OVSE: Oversampler Enable
This bit is set and cleared by software.
0: Oversampler disabled
1: Oversampler enabled
Note: Software is allowed to write this bit only when ADSTART = 0 (which ensures that no conversion
is ongoing).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. SMP[2:0]
rw
Bits 31:3 Reserved, must be kept at reset value.
Bits 2:0 SMP[2:0]: Sampling time selection
These bits are written by software to select the sampling time that applies to all channels.
000: 1.5 ADC clock cycles
001: 3.5 ADC clock cycles
010: 7.5 ADC clock cycles
011: 12.5 ADC clock cycles
100: 19.5 ADC clock cycles
101: 39.5 ADC clock cycles
110: 79.5 ADC clock cycles
111: 160.5 ADC clock cycles
Note: The software is allowed to write this bit only when ADSTART = 0 (which ensures that no
conversion is ongoing).
