RM0367 Rev 7 691/1043

RM0367 Real-time clock (RTC)

694

27.7.18 RTC alarm B sub second register (RTC_ALRMBSSR)

This register can be written only when ALRBE is reset in RTC_CR register, or in initialization

mode.

This register is write protected.The write access procedure is described in Section : RTC

Address offset: 0x48

RTC domain reset value: 0x0000 0000

System reset: not affected

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. MASKSS[3:0] Res. Res. Res. Res. Res. Res. Res. Res.

rw rw rw rw

1514131211109876543210

Res. SS[14:0]

rw rw rw rw rw rw rw rw rw rw rw rw w rw rw

Bits 31:28 Reserved, must be kept at reset value.

Bits 27:24 MASKSS[3:0]: Mask the most-significant bits starting at this bit

0x0: No comparison on sub seconds for Alarm B. The alarm is set when the seconds unit is

incremented (assuming that the rest of the fields match).

0x1: SS[14:1] are don’t care in Alarm B comparison. Only SS[0] is compared.

0x2: SS[14:2] are don’t care in Alarm B comparison. Only SS[1:0] are compared.

0x3: SS[14:3] are don’t care in Alarm B comparison. Only SS[2:0] are compared.

...

0xC: SS[14:12] are don’t care in Alarm B comparison. SS[11:0] are compared.

0xD: SS[14:13] are don’t care in Alarm B comparison. SS[12:0] are compared.

0xE: SS[14] is don’t care in Alarm B comparison. SS[13:0] are compared.

0xF: All 15 SS bits are compared and must match to activate alarm.

The overflow bits of the synchronous counter (bits 15) is never compared. This bit can be

different from 0 only after a shift operation.

Bits 23:15 Reserved, must be kept at reset value.

Bits 14:0 SS[14:0]: Sub seconds value

This value is compared with the contents of the synchronous prescaler counter to determine

if Alarm B is to be activated. Only bits 0 up to MASKSS-1 are compared.
