Low-power universal asynchronous receiver transmitter (LPUART) RM0367
856/1043 RM0367 Rev 7
30.5 LPUART in low-power mode
30.6 LPUART interrupts
The LPUART interrupt events are connected to the same interrupt vector (see Figure 266).
• During transmission: Transmission Complete, Clear to Send, Transmit data Register
empty or Framing error interrupt.
• During reception: Idle Line detection, Overrun error, Receive data register not empty,
Parity error, Noise Flag, Framing Error, Character match, etc.
These events generate an interrupt if the corresponding Enable Control Bit is set.
Table 153. Effect of low-power modes on the LPUART
Mode Description
Sleep No effect. USART interrupt causes the device to exit Sleep mode.
Low-power run No effect.
Low-power sleep
No effect. USART interrupt causes the device to exit Low-power sleep
mode.
Stop
The LPUART is able to wake up the MCU from Stop mode when the
UESM bit is set and the LPUART clock is set to HSI16 or LSE.
The MCU wakeup from Stop mode can be done using either the standard
RXNE or the WUF interrupt.
Standby
The LPUART is powered down and must be reinitialized when the device
has exited from Standby mode.
Table 154. LPUART interrupt requests
Interrupt event Event flag
Enable
Control bit
Transmit data register empty TXE TXEIE
CTS interrupt CTSIF CTSIE
Transmission Complete TC TCIE
Receive data register not empty (data ready to be read) RXNE
RXNEIE
Overrun error detected ORE
Idle line detected IDLE IDLEIE
Parity error PE PEIE
Noise Flag, Overrun error and Framing Error in multibuffer
communication.
NF or ORE or FE EIE
Character match CMF CMIE
Wakeup from Stop mode WUF
(1)
1. The wUF interrupt is active only in Stop mode.
WUFIE
