The frequency generator allows you to achieve various LCD frame rates starting from an
LCD input clock frequency (LCDCLK) which can vary from 32 kHz up to 1 MHz.
3 different clock sources can be used to provide the LCD clock (LCDCLK/RTCCLK):
• 32 kHz Low speed external RC (LSE)
• 32 kHz Low speed internal RC (LSI)
• High speed external (HSE) divided by 2, 4, 8 or 16 to obtain a 1 MHz clock
17.4.2 Frequency generator
This clock source must be stable in order to obtain accurate LCD timing and hence
minimize DC voltage offset across LCD segments. The input clock LCDCLK can be divided
by any value from 1 to 2
15
x 31 (see Section 17.7.2: LCD frame control register (LCD_FCR)
on page 407). The frequency generator consists of a prescaler (16-bit ripple counter) and a
16 to 31 clock divider. The PS[3:0] bits, in the LCD_FCR register, select LCDCLK divided by
2
PS[3:0]
. If a finer resolution rate is required, the DIV[3:0] bits, in the LCD_FCR register, can
be used to divide the clock further by 16 to 31. In this way you can roughly scale the
frequency, and then fine-tune it by linearly scaling the clock with the counter. The output of
the frequency generator block is f
ck_div
which constitutes the time base for the entire LCD
controller. The ck_div frequency is equivalent to the LCD phase frequency, rather than the
frame frequency (they are equal only in case of static duty). The frame frequency (f
frame
) is
obtained from f
ck_div
by dividing it by the number of active common terminals (or by
multiplying it for the duty). Thus the relation between the input clock frequency (f
LCDCLK
) of
the frequency generator and its output clock frequency f
ck_div
is:
This makes the frequency generator very flexible. An example of frame rate calculation is
shown in Table 74.
Table 74. Example of frame rate calculation
LCDCLK PS[3:0] DIV[3:0] Ratio Duty f
frame
32.768 kHz 3 1 136 1/8 30.12 Hz
32.768 kHz 4 1 272 1/4 30.12 Hz
32.768 kHz 4 6 352 1/3 31.03 Hz
32.768 kHz 5 1 544 1/2 30.12 Hz
32.768 kHz 6 1 1088 static 30.12 Hz
32.768 kHz 1 4 40 1/8 102.40 Hz
32.768 kHz 2 4 80 1/4 102.40 Hz
32.768 kHz 2 11 108 1/3 101.14 Hz
32.768 kHz 3 4 160 1/2 102.40 Hz
32.768 kHz 4 4 320 static 102.40 Hz
1.00 MHz 6 3 1216 1/8 102.80 Hz
f
ckdiv
f
LCDCLK
2
PS
16 DIV+()×
---------------------------------------------=
f
frame
f
ckdiv
duty×=
