Reset and clock control (RCC) RM0367
194/1043 RM0367 Rev 7
7.3.5 Clock interrupt enable register (RCC_CIER)
Address: 0x10
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access
Bits 7:4 HPRE[3:0]: AHB prescaler
These bits are set and cleared by software to control the division factor of the AHB clock.
Caution: Depending on the device voltage range, the software has to set correctly these bits
to ensure that the system frequency does not exceed the maximum allowed
frequency (for more details please refer to the Dynamic voltage scaling management
section in the PWR chapter.) After a write operation to these bits and before
decreasing the voltage range, this register must be read to be sure that the new
value has been taken into account.
0xxx: SYSCLK not divided
1000: SYSCLK divided by 2
1001: SYSCLK divided by 4
1010: SYSCLK divided by 8
1011: SYSCLK divided by 16
1100: SYSCLK divided by 64
1101: SYSCLK divided by 128
1110: SYSCLK divided by 256
1111: SYSCLK divided by 512
Bits 3:2 SWS[1:0]: System clock switch status
These bits are set and cleared by hardware to indicate which clock source is used as system
clock.
00: MSI oscillator used as system clock
01: HSI16 oscillator used as system clock
10: HSE oscillator used as system clock
11: PLL used as system clock
Bits 1:0 SW[1:0]: System clock switch
These bits are set and cleared by software to select SYSCLK source.
Set by hardware to force MSI selection when leaving Standby mode or in case of failure of
the HSE oscillator used directly or indirectly as system clock (if the Clock Security System is
enabled).
00: MSI oscillator used as system clock
01: HSI16 oscillator used as system clock
10: HSE oscillator used as system clock
11: PLL used as system clock
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. Res. Res. Res. Res.
CSS
LSE
HSI48
RDYIE
MSI
RDYIE
PLL
RDYIE
HSE
RDYIE
HSI16
RDYIE
LSE
RDYIE
LSI
RDYIE
rw rw rw rw rw rw rw rw
