General-purpose timers (TIM21/22) RM0367
598/1043 RM0367 Rev 7
22.4.14 TIM21 option register (TIM21_OR)
Address offset: 0x50
Reset value: 0x0000
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. TI2_RMP TI1_RMP ETR_RMP
rw rw rw rw rw rw
Bits 15:6 Reserved, must be kept at reset value.
Bit 5 TI2_RMP: Timer21 TI2 (connected to TIM21_CH1) remap
This bit is set and cleared by software.
0: TIM21 TI2 input connected to GPIO. Refer to the Alternate function mapping table in the
device datasheet.
1: TIM21 TI2 input connected to COMP2_OUT
Bits 4:2 TI1_RMP: Timer21 TI1 (connected to TIM21_CH1) remap
This bit is set and cleared by software.
000: TIM21 TI1 input connected to GPIO. Refer to the Alternate function mapping table in the
device datasheet.
001:TIM21 TI1 input connected to RTC WAKEUP interrupt
010: TIM21 TI1 input connected to HSE_RTC clock
011: TIM21 TI1 input connected to MSI clock
100: TIM21 TI1 input connected to LSE clock
101: TIM21 TI1 input connected to LSI clock
110: TIM21 TI1 input connected to COMP1_OUT
111: TIM21 TI1 input connected to MCO clock
Bits 1:0 ETR_RMP: Timer21 ETR remap
This bit is set and cleared by software.
00: TIM21 ETR input connected to GPIO. Refer to the Alternate function mapping table in the
device datasheet.
01: TIM21 ETR input connected to COMP2_OUT
10: TIM21 ETR input connected to COMP1_OUT
11: TIM21 ETR input connected to LSE clock
