Touch sensing controller (TSC) RM0367

430/1043 RM0367 Rev 7

18.6.10 TSC I/O group x counter register (TSC_IOGxCR)

x represents the analog I/O group number.

Address offset: 0x30 + 0x04 * x, (x = 1..8)

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

Res. Res. CNT[13:0]

rrrrrrrrrrrrrr

Bits 31:14 Reserved, must be kept at reset value.

Bits 13:0 CNT[13:0]: Counter value

These bits represent the number of charge transfer cycles generated on the analog I/O

group x to complete its acquisition (voltage across C

has reached the threshold).
