Extended interrupt and event controller (EXTI) RM0367

296/1043 RM0367 Rev 7

The 30 lines are connected as shown in Table 56: EXTI lines connections:

Table 56. EXTI lines connections

EXTI line Line source Line type

0-15 GPIO configurable

16 PVD configurable

17 RTC alarm configurable

18 USB wakeup event direct

RTC tamper or timestamp or

CSS_LSE

configurable

20 RTC wakeup timer configurable

21 COMP1 output configurable

22 COMP2 output configurable

23 I2C1 wakeup direct

24 I2C3 wakeup direct

25 USART 1 wakeup direct

26 USART2 wakeup direct

27 Reserved

28 LPUART1 wakeup direct

29 LPTIM1 wakeup direct
