RM0367

62/1043 RM0367 Rev 7

APB1

0X4000 8000 - 0X4000 FFFF 32 K Reserved -

0X4000 7C00 - 0X4000 7FFF 1 K LPTIM1

Section 24.7.9: LPTIM register

map

0X4000 7800 - 0X4000 7BFF 1K I2C3

Section 28.7.12: I2C register

map

0X4000 7400 - 0X4000 77FF 1 K DAC1/2

Section 15.10.15: DAC register

map

0X4000 7000 - 0X4000 73FF 1 K PWR

Section 6.4.3: PWR register

map

0X4000 6C00 - 0X4000 6FFF 1 K CRS Section 8.7.5: CRS register map

0X4000 6800 - 0X4000 6BFF 1 K Reserved -

0X4000 6000 - 0X4000 67FF 2 K

USB (SRAM

512x16bit)

0X4000 5C00 - 0X4000 5FFF 1 K USB FS

Section 32.6.3: USB register

map

Table 3. STM32L0x3 peripheral register boundary addresses

(1)

(continued)

Bus Boundary address Size (bytes) Peripheral Peripheral register map
