Direct memory access controller (DMA) RM0367
288/1043 RM0367 Rev 7
Refer to Section 2.2 for the register boundary addresses.
0x064
DMA_CMAR5 MA[31:0]
Reset value 00000000000000000000000000000000
0x068 Reserved Reserved.
0x06C
DMA_CCR6
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
MEM2MEM
PL[1:0]
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR
TEIE
HTIE
TCIE
EN
Reset value 000000000000000
0x070
DMA_CNDTR6
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
NDTR[15:0]
Reset value 0000000000000000
0x074
DMA_CPAR6 PA[31:0]
Reset value 00000000000000000000000000000000
0x078
DMA_CMAR6 MA[31:0]
Reset value 00000000000000000000000000000000
0x07C Reserved Reserved.
0x080
DMA_CCR7
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
MEM2MEM
PL[1:0]
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR
TEIE
HTIE
TCIE
EN
Reset value 000000000000000
0x084
DMA_CNDTR7
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
NDTR[15:0]
Reset value 0000000000000000
0x088
DMA_CPAR7 PA[31:0]
Reset value 00000000000000000000000000000000
0x08C
DMA_CMAR7 MA[31:0]
Reset value 00000000000000000000000000000000
0x090 to
0x0A4
Reserved Reserved.
0x0A8
DMA_CSELR
Res.
Res.
Res.
Res.
C7S[3:0] C6S[3:0] C5S[3:0] C4S[3:0] C3S[3:0] C2S[3:0] C1S[3:0]
Reset value 0000000000000000000000000000
Table 54. DMA register map and reset values (continued)
Offset Register
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
