09/03
6-6
DC 3535/2240/1632, WC M24
DC Quick, dC100
Initial issue
General Procedures and Information
dC100 Service Entry
When entering Diagnostics, this routine allows you to view faults in progress, Non-Zero Jams
and HFSI items requiring replacement. Service entry allows you to view product information,
such as:
• Product Code
• Machine Serial Number
• Total Copies
• Copies since Last Call
• IOT Software Version
Procedure
1. Enter the Diagnostic Mode. Refer to Entering Diagnostic Mode using the PWS.
2. Check the HFSI Requiring Replacement.
3. Check the Non-Zero Jams. Jams that have occurred since the last service exit with the
Complete Closeout option selected. Check for any Jams that have a high number of
occurrences.
4. Check the Faults In Progress. If any faults in progress are displayed, troubleshoot
accordingly.
5. Select the Refresh button to have the PWS request and receive the latest information on
Total Copies, Copies Since Last Call, Non-Zero Jams or HFSI Requiring Replacement.
371 Configuration Page Allows viewing of current software version
and Market Place setting, Machine Con-
figuration, Output Device(s), Accessories,
Feature Config., and Input Device.
These settings can be changed to align
with the machine configuration.
612 Color Test Pattern Print Generates test pattern from the pattern
generator in the machine. Patterns for use
in identifying IQ problems, setting registra-
tion, and performing adjustments
685 Regicon Color Registration/Skew setup
921 ATC Calibration Enter ATC Sensor Calibration code into
NVM.
922 TRC Control/Toner Density
Adjustment
Measure the gray scale patch by the ADC
sensor. Make the LUT for IOT TRC cor-
rection.
924 TRC Adjustment Manually fine adjust each color (low/mid/
high density) in PG.
934 ADC/AGC Setup Execute automatic adjustment of the ADC
Sensor Gain.
945 IIT calibration 1. Calculate and set the white reference
compensation coefficient.
2. Correct the IIT sensitivity variation.
956 Belt Edge Learn Set up the Belt Edge Sensor.
Table 1 dC Routines
dC Number Name Description
To Next Page
