Xerox DocuColor 2240 Service Manual

09/03
6-73
DC 3535/2240/1632, WC M24
790-xxx ESS Panel Display Setting NVM List
General Procedures and Information
Initial issue
790-xxx ESS Panel Display Setting NVM List
Table 1 Chain 790
Chain-Link Name Default Range Description
790-001 Startup Display Setting 0 0~2 0=Features Programming Screen; 1=Job Management Screen; 2=Machine Status Screen
790-002 Function Setup Startup Display 1 0~3 0=Menu; 1=Copy; 3=Scanner
790-003 Fax Broadcast/Polling Confirmation
Display
1 0~1 0 = No display; 1 = Display
790-004 Toner Near Empty advance notification 1 0~1 0=No display; 1=Display
790-006 Tray 5 Paper sizes _1 18 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-007 Tray 5 Paper sizes _2 17 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-008 Tray 5 Paper sizes _3 20 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-009 Tray 5 Paper sizes _4 22 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-010 Tray 5 Paper sizes _5 30 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-011 Tray 5 Paper sizes _6 11 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-012 Tray 5 Paper sizes _7 10 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
