09/03
3-7
DC 3535/2240/1632, WC M24
IQ5
Image Quality
Initial issue
IQ5 Residual Image (Ghosting) RAP
Initial Actions
• Check the end-of-life counter for the Drum Cartridge. If the unit is at or near end-of-life,
replace the Drum Cartridge (see Machine Consumables in Section 6).
NOTE: Some ghosting on transparencies is unavoidable.
• If the problem occurs only with certain types of media, ensure that the media in use is
within specification, and that the customer is aware of correct operation of print driver.
• If the distance between the intended image and the residual image has a fixed rate of rep-
etition, go to the IQ14 RAP. Return to this procedure if the problem persists.
Procedure
The problem is with a single primary color
YN
Remove the Fuser. Examine the Heat Roll and Pressure Roll for evidence of toner offset-
ting. There is Toner adhering to the Heat Roll.
YN
CAUTION
Do not attempt to clean the cleaning blade. It WILL be damaged if any wiping or
excessive pressure is applied.
Check for a residual image on the Transfer Belt. Repair or replace the IBT Cleaner
Assembly (PL 5.3) as required.
Check the 2nd BTR for contamination. Clean/replace as required
Clean the Heat Roll. If the problem persists, replace the Fuser (PL 7.1).
Check the Erase Lamp for the affected color:
• Enter dC330 [009-045] (C, Y, or M), or [009-042] (K), as appropriate.
• Remove the Drum cartridge for the affected color.
• check for light along the mounting rail left side
The Erase lamp is lit.
YN
Go to Flag 1 (C), Flag 2 (Y), Flag 3 (M), or Flag 4 (K). Check for an open circuit. If the
wires are OK, replace the Erase Lamp (PL 4.2) for the affected color. If the problem per-
sists, Replace the MCU PWB (PL 13.1).
Go to the IQ21 RAP. Check for a short circuit in the Developer bias circuit of the affected color.
To Next Page
