Xerox DocuColor 2240

09/03
2-671
DC 3535/2240/1632, WC M24
116-380, 116-381
Status Indicator RAPs
Initial issue
116-380 MF UI Cont Software
Fatal error of MF UI Cont
Due to an error during the software processing, the subsequent processes cannot be per-
formed.
Initial Actions
Switch power off then on. If the problem persists, continue with the procedure.
Procedure
Perform GP 3. If the problem continues, reload system software. If the problem persists,
replace the ESS PWB (PL 13.1).
116-381 Data Link Layer Error between Cont and UI
Panel
Controller - MF UI panel: Communication error on the Data Link layer
At the communication between the ESS and Panel, the ESS detected an initialization error of
SCOPE, a message sending error, or retrieve error of the received data.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Perform re-installation of the ESS or Panel software.
If the problem continues, replace the ESS PWB (PL 13.1).
If the problem continues, replace the Control Panel (PL 18.2).
