09/03
6-141
DC 3535/2240/1632, WC M24
Change Tag Introduction, DC 2240/1632 IOT/Pro-
General Procedures and Information
Initial issue
Change Tag Introduction
Important modifications to the copier are identified by a tag number which is recorded on a tag
matrix. The tag matrix for the IOT (Processor) is molded into the inside of the Front Door. The
DADF tag matrix is a label affixed to the rear cover of the DADF.
This section describes all of the tags associated with the copier, as well as multinational appli-
cability, classification codes, and permanent or temporary modification information.
Classification Codes
A tag number may be required to identify differences between parts that cannot be inter-
changed, or differences in diagnostic, repair, installation, or adjustment procedures.
A tag number may also be required to identify the presence of optional hardware, special non-
volatile memory programming, or whether mandatory modifications have been installed. Each
tag number is given a classification code to identify the type of change that the tag has made.
The classification codes and their descriptions are listed in the table below.
DC 2240/1632 IOT/Processor (P) Tags
The following IOT change tags have been issued for the DocuColor 2240/1632:
TAG: P1
CLASS: R
USE: ALL
MFG SERIAL NUMBERS: LVE: 180908 LVF: 311200422x
NAME: V3.8 Software Upgrade
PURPOSE:
KIT NUMBER: 301E49540
REFERENCE:
TAG: P2
CLASS: O
USE: ALL
NAME: V4.1 Software Upgrade
PURPOSE: Software upgrade for Token Ring compatibility.
KIT NUMBER: 301E49760
REFERENCE:
TAG: P3
CLASS: R
USE: ALL
MFG SERIAL NUMBERS: LVE: 182520 LVF: 3112024025
NAME: V4.2 Software Upgrade
PURPOSE:
KIT NUMBER: 301E49541
REFERENCE:
Table 1
Classification Code Description
M Mandatory tag.
N Tag not installed in the field.
O Optional tag.
R Repair tag.
