09/03
3-33
DC 3535/2240/1632, WC M24
Deletions, High Frequency Bands
Image Quality
Initial issue
Deletions
Figure 1 Deletions Defect Sample
Cause
Defective IBT Belt, damp paper, uneven charge.
Corrective Action
Go to the IQ7 RAP.
High Frequency Bands
Figure 1 High Freq. Bands Defect Sample
Cause
Faulty ROS Assembly or Photoreceptor/Developer Housing gear or bearing problem.
Corrective Action
Go to the IQ14 RAP.
