Xerox DocuColor 2240 Service Manual

09/03
6-101
DC 3535/2240/1632, WC M24
870-xxx ESS Diagnosis Setting NVM List
General Procedures and Information
Initial issue
870-xxx ESS Diagnosis Setting NVM List
Table 1 Chain 870
Chain/Link Name Default Range Description
870-001 TBD Normal - Normal, Diag (Auto setting)
870-010 CRU #1 PR Wear previous value - - 0~99999999
870-011 CRU #2 PR Wear previous value - - 0~99999999
870-012 CRU #3 PR Wear previous value - - 0~99999999
870-013 CRU #4 PR Wear previous value - - 0~99999999
870-014 #1CRU Warning previous value - - 0~99999999
870-015 #1DRUM Total cycles previous value - - 0~99999999
870-016 #2DRUM Total cycles previous value - - 0~99999999
870-017 #3DRUM Total cycles previous value - - 0~99999999
870-018 #4DRUM Total cycles previous value - - 0~99999999
870-019 #1DRUM DC cycles previous value - - 0~99999999
870-020 #2DRUM DC cycles previous value - - 0~99999999
870-021 #3DRUM DC cycles previous value - - 0~99999999
870-022 #4DRUM DC cycles previous value - - 0~99999999
870-023 #1DRUM AC cycles previous value - - 0~99999999
870-024 #2DRUM AC cycles previous value - - 0~99999999
870-025 #3DRUM AC cycles previous value - - 0~99999999
870-026 #4DRUM AC cycles previous value - - 0~99999999
870-027 IBT Belt (IMPS) previous value - - 0~99999999
870-028 IBT Belt (cycle) previous value - - 0~99999999
870-029 1st BTR previous value - - 0~99999999
870-030 Back Up Roll previous value - - 0~99999999
870-031 2nd BTR Unit previous value - - 0~99999999
870-032 Bearing BTR previous value - - 0~99999999
870-033 Trim within Transfer Module previous
value
- - 0~99999999
870-034 Belt Cleaner Blade previous value - - 0~99999999
870-035 Belt Cleaner Film Seal previous value - - 0~99999999
870-037 Tray 5 # of feeds previous value - - 0~99999999
870-038 3TM Tray 2 # of feeds previous value - - 0~99999999
870-039 3TM Tray 3 # of feeds previous value - - 0~99999999
870-040 3TM 4Tray # of feeds previous value - - 0~99999999
870-042 TTM Tray 2 # of feeds previous value - - 0~99999999
870-043 TTM Tray 3 # of feeds previous value - - 0~99999999
870-044 TTM 4Tray # of feeds previous value - - 0~99999999
870-045 PV (CV) Counter for filter life previous
value
- - 0~99999999
