Xerox DocuColor 2240 Service Manual

09/03
6-30
DC 3535/2240/1632, WC M24
744--xxx Fuser NVM List
Initial issue
General Procedures and Information
744--xxx Fuser NVM List
Table 1 Chain 744
Chain-Link Name Default Range Description
744-001 STS-1 Cont Temp- Low Pwr Mode 80 0~160
(1 bit=1 deg. C)
Main-Lamp temperature control in Low-Power Mode. Setting the default as 0 degrees Celsius is same as Fuser-
Off. It is necessary for high temperature for recovery Time Claim.
744-002 STS-2 Cont Temp in Low Pwr Mode 80 0~160
(1 bit=1 deg. C)
Sub-Lamp temperature control in Low-Power Mode. Setting the default as 0 degrees Celsius is same as Fuser-Off.
It is necessary for high temperature for recovery Time Claim.
744-003 UM status by High Temperature Error
Detection
0 0~2 0 (Normal) or 1 (STS-1 High Temperature Error Detection) or 2 (STS-2 High Temperature Error Detection).UM Sta-
tus occurs when either STS-1 or STS-2 High Temperature Error Detection is detected. Once this occurs, UM can-
not be canceled unless this NVM value is changed to 0 by entering the Diag Mode in the Interlock-Open status of
the M/C-Front Cover.
744-004 STS-2 High-temp-not-ready Temp 230 150~250
(1 bit=1 deg.C)
Once the STS-2 reaches high temperature not-ready temperature, the Fuser is moved to sagging status. This is
because when continuous run is performed for A5SEF and below, Temperature Distribution Control would fail.
744-005 STS-1 Ready Temperature 150 100~150 For optimization of Ready to Copy temperature distribution (1 bit=1 deg.C)
744-006 STS-2 Ready temperature 127 100~150 For optimization of Ready to Copy temperature distribution (1 bit=1 deg.C).
744-007 STS-1 Stand-by temperature 160 100~200 For optimization of Standby temperature distribution (1 bit=1 deg.C).
744-008 STS-2 Stand-by temperature 160 100~200 For optimization of Standby temperature distribution (1 bit=1 deg.C).
744-013 STS-1 Target run temperature#6 190 100~200 For optimization of temperature distribution - plain paper 1 from 273.2 ~ 320 mm wide (1 bit=1 deg.C).
744-028 STS-1 Target run temperature#21 190 100~200 For optimization of temperature distribution - Transparency LEF (1 bit=1 deg.C).
744-031
DC3535 only
STS-1 Target run temperature#3 140 100~200 For optimization of temperature distribution - plain paper 1 from 236.7~ 196.2 mm wide (1 bit=1 deg.C).
744-032
DC3535 only
STS-1 Target run temperature#4 140 100~200 For optimization of temperature distribution - plain paper 1 from 165.4 ~ 196.2 mm wide (1 bit=1 deg.C).
744-033
DC3535 only
STS-1 Target run temperature#5 140 100~200 For optimization of temperature distribution - plain paper 1 less than 165.4 mm wide (1 bit=1 deg.C).
744-036
DC3535 only
STS-2 Target run temperature#8 140 100~200 For optimization of temperature distribution - plain paper 2 from 236.7~ 196.2 mm wide (1 bit=1 deg.C).
744-037
DC3535 only
STS-2 Target run temperature#9 140 100~200 For optimization of temperature distribution - plain paper 2 from 165.4 ~ 196.2 mm wide (1 bit=1 deg.C).
744-038
DC3535 only
STS-2 Target run temperature#10 140 100~200 For optimization of temperature distribution - plain paper 2 less than 165.4 mm wide (1 bit=1 deg.C).
744-041
DC3535 only
STS-2 Target run temperature#13 140 100~200 For optimization of temperature distribution - Heavy Weight 1 from 236.7~ 196.2 mm wide (1 bit=1 deg.C).
744-042
DC3535 only
STS-2 Target run temperature#14 140 100~200 For optimization of temperature distribution - Heavy Weight 1 from 165.4 ~ 196.2 mm wide (1 bit=1 deg.C).
744-043
DC3535 only
STS-2 Target run temperature#15 140 100~200 For optimization of temperature distribution - Heavy Weight 1 less than 165.4 mm wide (1 bit=1 deg.C).
744-046
DC3535 only
STS-2 Target run temperature#18 140 100~200 For optimization of temperature distribution - Heavy Weight 2 from 236.7~ 196.2 mm wide (1 bit=1 deg.C).
744-047
DC3535 only
STS-2 Target run temperature#19 140 100~200 For optimization of temperature distribution - Heavy Weight 2 from 165.4 ~ 196.2 mm wide (1 bit=1 deg.C).
744-048
DC3535 only
STS-2 Target run temperature#20 140 100~200 For optimization of temperature distribution - Heavy Weight 2 less than 165.4 mm wide (1 bit=1 deg.C).
744-049
DC3535 only
STS-2 Target run temperature#21 140 100~200 For optimization of temperature distribution - Transparency LEF (1 bit=1 deg.C).
