09/03
6-31
DC 3535/2240/1632, WC M24
744--xxx Fuser NVM List
General Procedures and Information
Initial issue
744-050
DC3535 only
STS-2 Target run temperature#22 140 100~200 For optimization of temperature distribution - Transparency SEF (1 bit=1 deg.C).
744-051 Environment temperature correction 3 0~5 Environment dependent correction coefficient for level of fusing. Temperature AD value shift amount when the
environment temperature varies 1 degrees Celsius from 20 degrees Celsius. Corrects the target temperature of
Ready temperature/Standby temperature/RUN. Both STS-1 and STS-2 have the same temperature. Corrects
between 10 ~ 20 degrees Celsius. Correction is not performed outside this range. 0=No correction; 1=0.2 degrees
Celsius/Environment Temperature (Maximum 2 degrees Celsius); 2=0.4 degrees Celsius/Environment Tempera-
ture (Maximum 4 degrees Celsius); 3=0.6 degrees Celsius/Environment Temperature (Maximum 6 degrees Cel-
sius); 4=0.8 degrees Celsius/Environment Temperature (Maximum 8 degrees Celsius); 5=1.0 degrees Celsius/
Environment Temperature (Maximum 10 degrees Celsius)
744-052 STS-1 Low Temp Not-ready Temp 125 100~150 Once the STS-1 reaches Low Temperature Not-Ready Temperature, the Fuser is moved to sagging status to avoid
poor fusing. (1 bit=1 deg.C)
744-053 STS-2 Low Temp Not-ready Temp 125 100~150
(1 bit=1 deg.C)
Once the STS-2 reaches Low Temperature Not-Ready Temperature, the Fuser is moved to sagging status to avoid
poor fusing.
744-054 HFSI Counter Index 0 0~5 For HFSI Counter Symmetry
744-055
DC3535 only
STS-1, -2 shift from target run temp#1 5 0~30 Optimization of temperature - plain paper 1 (1 bit=1 deg.C)
744-056
DC3535 only
STS-1, -2 shift from target run temp#2 10 0~30 Optimization of temperature - plain paper 1 (1 bit=1 deg.C)
744-057
DC3535 only
STS-1, -2 shift from target run temp#3 15 0~30 Optimization of temperature - plain paper 1 (1 bit=1 deg.C)
744-067
DC3535 only
STS-1, -2 shift from target run temp#13 5 0~30 Optimization of temperature - transparency (1 bit=1 deg.C)
744-068
DC3535 only
STS-1,-2 shift from target run temp#14 10 0~30 Optimization of temperature - transparency
744-069
DC3535 only
STS-1,-2 shift from target run temp#15 15 0~30 Optimization of temperature - transparency
744-085 Plain Paper S Setting Temperature 5 0~5 0=Light Weight paper (55~63gsm); 1=Plain paper (64~70gsm); 2=Plain paper (71~80gsm); 3=Bond (81~89gsm);
4=Bond (90~98gsm); 5=Bond (99~105gsm)
744-088
DC3535 only
Fuser temp switch - media #3 5 0~20 Fuser temperature shift qty (-) for plain paper 2
744-089
DC3535 only
Fuser temp switch - media #4 5 0~20 Fuser temperature shift qty (+) for plain paper 2
744-091
DC3535 only
Temp Cont - Auto Dup 5 0~10 Plain paper 1 (1 bit=1 deg.C)
744-092
DC3535 only
Temp Cont - Auto Dup 5 0~10 Plain paper 2 (1 bit=1 deg.C)
744-136
DC3535 only
Main Lamp delay time 10 0~19 (1 bit=10 msec.)
744-194
DC3535 only
Environment Sensor temperature 40 0~80 (1 deg.C/
bit)
Environment Sensor temperature read @ power on. Environment controlled based on this factor
744-195
DC3535 only
Environment correction working tem-
perature (STS-1, 2)
35 20~50
(1 bit=1 deg.C)
When temperature of STS1/2 is the set value or lower, the environment sensor temperature is read.
Table 1 Chain 744
Chain-Link Name Default Range Description
