Xerox DocuColor 2240 Service Manual

09/03
2-174
DC 3535/2240/1632, WC M24
8-629, 8-630
Initial issue
Status Indicator RAPs
8-629 Regicon Skew (Patch Y)
During A1 Patch detection, skew deviation for Y exceeded tolerance.
NOTE: Machine operation continues. Status Code not displayed on UI. Status Code logged in
History.
Initial Actions
Clean MOB Sensor.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Adjust the Color Registration (ADJ 9.6).
8-630 Regicon Skew (Patch M)
During A1 Patch detection, skew deviation for M exceeded tolerance.
NOTE: Machine operation continues. Status Code not displayed on UI. Status Code logged in
History.
Initial Actions
Clean MOB Sensor.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Adjust the Color Registration (ADJ 9.6).
