09/03
6-23
DC 3535/2240/1632, WC M24
720-xxx ESS Meter/Counter NVM List, 740--xxx IOT
General Procedures and Information
Initial issue
740--xxx IOT Manager NVM List
741--xxx Drive NVM List
720-016 Backup1 Copy-Full Color - 0~1999999 read only
720-017 Backup1 Copy-Color2 - 0~1999999 read only
720-018 Backup1 Copy-B&W - 0~1999999 read only
720-019 Backup1 Fax-Full Color - 0~1999999 read only
720-020 Backup1 Fax-B&W - 0~1999999 read only
720-046 Master large size B&W 0 0~1999999 read only
720-047 Master large size color 0 0~1999999 read only
720-048 Backup 1 large size B&W 0 0~1999999 read only
720-043 Backup 1 large size color 0 0~1999999 read only
Table 1 Chain 720
Chain-Link Name Default Range Description
Table 1 Chain 740
Chain-Link Name Default Range Description
740-020 Market Code XC=2; XE=3 - XC=2; XE=3
740-024 RegiCon Request Flag 0 0~255 0=Performed; 1=Not performed
740-025 Edge Check Request Flag 0 0~255 0=Performed; 1=Not performed
740-026 ProCon Request Flag 0 0~255 0=Performed; 1=Not performed
740-027 Temperature when act RegiCon 0 0~255 20 degrees C/ bit
740-028 Date when act PowerOn-SetUp or
NextDay-SetUp
00~255
740-028 Date when act PowerOn-SetUp or
NextDay-SetUp
00~255
740-029 Power Off Delay Switch 0 0~1 0=Delay on; 1=Delay off
Table 1 Chain 741
Chain-Link Name Default Range Description
741-054
2240/1632
only
NVM_PR_MOT_HIGH_PULSE (PR
(Drum) Motor Speed Fine Adjustment
(Standard)
23 0~40 Performs fine adjustment of Drum speed at standard speed. Each bit raises or lowers the drum speed by
approx. 0.05% with respect to the initial value.
741-055
2240/1632
only
NVM_PR_MOT_LOW_PULSE (PR
(Drum) Motor Speed Fine Adjustment
(Heavy Weight /Transparency)
23 0~40 Fine adjusts the Drum speed at half speed. Each bit raises or lowers the drum speed by approx. 0.05% with
respect to the initial value.
741-056 Belt Home Fail Too Long counter 0 0~3 It is necessary to reset the counter to reenable operation if the value reaches 3.
741-057 NoPaperRun Mode SW 0 0~2 0=Normal NoPaperRun 1=MainMotor Stop 2=Main/Dev. Motor Stop
741-068
2240/1632
only
NVM_PR_MOT_DOUBLE_PULSE (PR
(Drum) Motor Speed Fine Adjustment
(Double Speed)
22 0~40 Fine adjusts the Drum Speed at double speed. Increases the Drum Speed by +1 (approx. 0.05%) with respect
to the initial value. Decreases the Drum Speed by -1 (approx. 0.05%).
741-111 Belt Length Variable 10 0~24 Correction of belt peripheral length for lead registration (0.2544 mm/bit)
