09/03
6-24
DC 3535/2240/1632, WC M24
741--xxx Drive NVM List
Initial issue
General Procedures and Information
741-112
3535 only
IBT Motor Reverse Switch 1 0~1 Switch to reverse IBT Motor rotation at job end
0=Disable; 1=Enable
741-113
3535 only
PR Motor Reverse Switch 0 0~1 Switch to reverse PR Motor rotation at job end
0=Disable; 1=Enable
741-114
3535 only
Reverse time 13 12~25 Time from the reverse rotation-start signal until the reverse rotation-disabling signal (10 msec/bit)
IBT: Time of step-up + constant speed
PR: Time from On to Off of Reverse rotation port
(Excluding time of step-down and stop)
741-115
3535 only
Threshold for PV Counter 200 1~65535 Reverse rotation interval by PV
741-113
3535 only
PV Counter for Drive 0 0~65535 Total PV from the previous reverse rotation
Table 1 Chain 741
Chain-Link Name Default Range Description
