DC 3535/2240/1632, WC M24
Detailed Maintenance Activities
Initial issue
Service Call Procedures
Detailed Maintenance Activities (HFSI)
Procedure
1. Clean the ADC Sensor on every call.
2. Enter Diagnostics and select dC135.
3. Perform the Service Actions in Table 1 for any High Frequency Service Item (HFSI)
counters that are over threshold or approaching the threshold. Using the customer's out-
put volume numbers (high, medium, or low volume), evaluate which HFSI actions should
be accomplished now to avoid an additional service call in the near future.
4. Refer to Cleaning Procedures for detailed cleaning instructions.
Table 1 High Frequency Service Items
Counter Name Threshold Service Action to be performed
006-802 IIT Scan
No. of scans (Including pre-scan) after HFSI
counter cleared
2400000 No action required - counter only
005-805 Document Feed
No. of DADF Feed after HFSI Counter
Cleared.
2400000 No action required - counter only
954-801 IBT Belt Assembly (DC 2240/1632) - 480K
(DC 3535) - 592.8K
increments by 1 for letter size or smaller;
by 2 for longer than letter size
Replace the IBT Assembly (PL 5.3)
954-802 2nd BTR Unit (DC 2240/1632) - 150K
(DC 3535) - 100K
Replace the 2nd BTR Unit (PL 2.8)
954-803 IBT Belt Cleaner Assy 100K Replace the IBT Belt Cleaner (PL 5.3)
Warning at 98.5K
954-804 Fuser 10000000 counts
Area conversion, with A4L = 100 counts/
sheet, 8.5x11 = 96 counts/sheet, 11x17
= 193 counts/sheet, A3 = 200 counts/
sheet, etc.
Replace the Fuser (PL 7.1)
Warning at 9000000 counts
954-805 Unused Counter 99999999 No action required - counter only
954-806 Tray 1 Feed counter 300K Replace the Roll Kit (PL 2.5).
954-807 Tray 5 Feed counter 300K Replace the Feed Roll Assembly and Retard Pad (PL 2.14).
954-808 Tray 2 Feed counter 300K Replace the Roll Kit (PL 16.8 for TTM or PL 15.4 for 3TM).
954-809 Tray 3 Feed counter 300K Replace the Roll Kit (PL 16.10 for TTM or PL 15.6 for 3TM).
954-810 Tray 4 Feed counter 300K Replace the Roll Kit (PL 16.12 for TTM or PL 15.8 for 3TM).
954-811
(DC 3535 only)
Black Developer Housing 592.8K
increments by 1 for letter size or smaller;
by 2 for longer than letter size
Replace the Black Developer Housing (PL 6.2)
954-812
(DC 3535 only)
Cyan Developer Housing 592.8K
increments by 1 for letter size or smaller;
by 2 for longer than letter size
Replace the Cyan Developer Housing (PL 6.2)
954-813
(DC 3535 only)
Magenta Developer Housing 592.8K
increments by 1 for letter size or smaller;
by 2 for longer than letter size
Replace the Magenta Developer Housing (PL 6.2)
954-814
(DC 3535 only)
Yellow Developer Housing 592.8K
increments by 1 for letter size or smaller;
by 2 for longer than letter size
Replace the Yellow Developer Housing (PL 6.2)
