DC 3535/2240/1632, WC M24
Common Tools, Product Tools and Test Patterns
General Procedures and Information
Initial issue
Common Tools Product Tools and Test Patterns
Table 1 Common Tools
Description Part Number
Screw Driver (-) 3 x 50 600T40205
Screw Driver (+) 6 x 100 600T1989
Screw Driver (+) NO.1 499T356
Stubby Driver (+) (-) 600T40210
Screw Driver (=) 100MM 499T355
Spanner and Wrench 5.5 x 5.5 600T40501
Spanner and Wrench 7x 7 600T40502
Hex Key Set 600T02002
Box Driver 5.5MM 600T1988
Side Cutting Nipper 600T40903
Round Nose Pliers 600T40901
Digital Multi-meter Set 600T2020
Interlock Cheater 600T91616
Silver Scale 150MM 600T41503
CE Tool Case 600T1901
Magnetic Screw Pick-up Tool 600T41911
Scriber Tool 600T41913
Magnetic pickup 600T41911
Loupe 600T42008
Flash Light 600T1824
Brush 600T41901
Tester Lead Wire (red) 600T 9583
Tester Lead Wire (black) 600T2030
Table 1 Tools and Test Patterns
Description Part Number
Color Test Pattern 82E13120
Geometric Test Pattern 82E8220
HVPS test probe (1/10X) 600T1653
HVPS test probe adapter 600T1996
Copy Paper Carrying Case 600T1999
Copy Paper Zip Lock Bag 600T2000
Xerox Color Xpressions Plus 24# 11×17 in, 3R5465
Colotech Plus - 90 gsm - A3 3R94642
Service and Machine NVM Log 700P97436
Serial cable 600T2058
Network Interface (Crossover) cable 600T02252
Parallel printer cable 117E19340
PWS power cord adapter 600T2018
L Probe 600T02177
Machine Resident Disk Kit
(Machine Settings Floppy)
300K63850
