09/03
6-25
DC 3535/2240/1632, WC M24
742--xxx Paper Handling NVM List
General Procedures and Information
Initial issue
742--xxx Paper Handling NVM List
Table 1 Chain 742
Chain-Link Name Default Range Description
742-001 Invert Clutch CW Off Timing 91 0~163 Paper inversion position adjustment (P Speed) (1bit=2.4462 msec.)
742-002 Invert Clutch CW Off Timing (MF-1) 90 0~259 Paper inversion position adjustment (Double Speed)
DC2240/1632: (1bit=1.31136 msec.)
DC3535: (1bit=1.5418 msec.)
742-003
DC3535 only
Invert Clutch CW Off Timing (104mm/
sec. Heavy 1)
91 0~259 Adjustment of paper inversion position (104mm/sec.) Heavy1
Clutch off 238msec after Fuser Exit sensor off
742-006 RegiLoop Length Adjust (Tray Standard
Paper)
41 0~81 Regi Loop Length Adjustment (P Speed) for Standard Paper from Tray (2.4462 msec/bit)
742-007 RegiLoop Length Adjust (Tray Standard
Paper)
41 0~81 Regi Loop Length Adjustment (Double Speed) for Standard Paper from Tray
DC2240/1632: (1bit=1.31136 msec.)
DC3535: (1bit=1.5418 msec.)
742-008
DC3535 only
RegiLoop Length Adjust (Tray Heavy 1) 41 0~81 Regi Loop Length Adjustment (P Speed) for Heavy Weight1paper from Tray (2.4462 msec/bit)
742-009 RegiLoop Length Adjust (Tray 5 Stan-
dard Paper)
41 0~81 Regi Loop Length Adjustment (P Speed) for Standard Paper from Tray 5 (1bit=2.4462 msec.)
742-010
DC3535 only
RegiLoop Length Adjust (Tray 5 Heavy
1)
41 0~81 Regi Loop Length Adjustment (P Speed) for Heavy Weight1paper from Tray 5 (2.4462 msec/bit)
742-011 RegiLoop Length Adjust (Tray 5 Stan-
dard Paper)
41 0~81 Regi Loop Length Adjustment (Double Speed) for Standard Paper from Tray 5 (1bit=1.322 msec.)
742-013 RegiLoop Length Adjust (Tray 5
Heavy2 Paper)
41 0~81 Regi Loop Length Adjustment (Half Speed) for Heavy Weight Paper from Tray 5.
DC2240/1632: (1bit=4.8924 msec.)
DC3535: (1bit=5.025ms msec.)
742-014 RegiLoop Length Adjust (DUP)
(2sheets of paper)
* 0~81 Regi Loop Length Adjustment (P Speed) from Up (Feeding length Letter-LEF and Shorter) (2.4462 msec/bit)
*default=41 for DC2240/1632; 33 for DC3535
742-015 RegiLoop Length Adjust (DUP) 64 0~152 Regi Loop Length Adjustment (Double Speed) from Dup (1bit=1.31136 msec.)
742-016 T/A Clutch On Timing (From Regi Start) 20 8~32 Synchronize adjustment to be same as Regi Clutch at Regi Start (-30~30 msec.) Default=0ms (2.4462 msec/bit)
742-017 Dup On Timing (From Regi Start) 20 0~40 Synchronize adjustment to be same as Regi Clutch at Regi Start (P Speed). (1bit=2.4462 msec.)
742-018 Full Stack Paper Sensing Condition * 1~12 Full Stack Detection Condition (1bit=5sec).
*Default=4 for DC2240/1632; 7 for DC3535
742-019 Full Stack Paper Cancel Condition 1 1~30 Full Stack Cancel Condition (1bit=1 sec.)
742-020 Feed Start Timing (Tray 5) 41 0~82 Feed Start Timing Adjustment from Pitch (P Speed) (850~1050 msec.). Default=950ms (1bit=2.4462 msec.)
742-021 Feed Start Timing (Tray 5) 150 0~300 Feed Start Timing Adjustment from Pitch (Double Speed) (100~500 msec.)
DC2240/1632: (1bit=1.31136 msec.)
DC3535: (1bit=1.5418 msec.)
742-022 Feed Motor Off Timing 10 0~35 Feed Motor Off Timing Adjustment from T/A Nip (1bit=10 msec.)
742-023 Regi Clutch Off Timing 41 0~81 Adjusts the time between the when paper rear edge passes the Regi Sensor and the Regi Clutch turns Off (P
Speed) (90~290 msec.). Default=190ms (1bit=2.4462 msec.)
742-024 Regi Clutch Off Timing 76 0~152 Adjusts the time between when the paper rear edge passes the Regi Sensor and the Regi Clutch Turns Off
(Double Speed)
DC2240/1632: (1bit=1.31136 msec.)
DC3535: (1bit=1.5418 msec.)
742-025 Adjust Side Regi (All) 25 0~50 Side Regi Adjustment (ALL, Offset value) (1bit=0.211mm)
To Next Page
