Xerox DocuColor 2240

09/03
6-15
DC 3535/2240/1632, WC M24
701--xxx Image Quality Setting NVM List, 710-xxx
General Procedures and Information
Initial issue
701--xxx Image Quality Setting NVM List
710-xxx DADF NVM List
Table 1 Chain 701
Chain-Link Name Default Range Description
701-912 ADC Gradation Compensation Validity
for A, B
1 0~1 0 = Invalid; 1 = Valid
701-924 Auto Gradation Compensation Validity
for A, B
1 0~1 0 = Invalid; 1 = Valid
701-929 Auto Gradation Compensation Validity
for E, F
1 0~1 0 = Invalid; 1 = Valid
Table 1 Chain 710
Chain-Link Name Default Range Description
710-001 ADF Fail Bypass 0 0~1 0=Bypass On 1=Bypass Off
710-002 JAM Bypass 0 0~1 0=Bypass On 1=Bypass Off
710-005 Regi Sensor Off to Belt Motor Slow-
down Step (Non CVT Mode)
250 217~283 No. of Steps after the Regi Sensor turned Off and until the Belt Motor started to reduce speed in the Non CVT
Mode. Lead Regi Adjustment Value=5 +/-5mm
710-006 DupMode RegiSensor On to Belt Mot.
Slowdown Step (Non CVT Mode)
44 19~69 No. of Steps after the Regi Sensor turned On and until the Belt Motor started to reduce speed in the Non CVT
Mode (Reverse & Reverse Output Loop) Regi Roll Loop Adjustment Value at Reverse & Reverse Output=4 +/-
5mm
710-012 8.5x11LEF Threshold 2093 1993~2193 Threshold to separated the size detection of 8.5x11LEF and 8x10LEF.
710-013 B5SEF/8x10SEF Switching 0 0~1 0=B5SEF(FX/XE/AP); 1=8x10SEF(XC)
710-014 11x15SEF/8K Switching (for AP mar-
ket)
0 0~1 11x15SEF; 1=8K
710-018 FS MAX value 2970 1297~3070 For customized registration of DADF Document Size Detection Decurler
710-019 FS MIN value 2970 1297~3070 For customized registration of DADF Document Size Detection Decurler
710-020 SS MAX value 2100 1297~4418 For customized registration of DADF Document Size Detection Decurler
710-021 SS MIN value 2100 1297~4418 For customized registration of DADF Document Size Detection Decurler
710-022 Document Size 8 3~20 For customized registration of DADF Document Size Detection Decurler
710-023 Document Process Direction 0 0~1 For customized registration of DADF Document Size Detection Decurler
710-024 DADF Doc Size Detection Table 0 0~1 For customized registration of DADF Document Size Detection Decurler
710-025 S Size Side2 Lead Regi Adjust 250 217~283 Side 2 Lead Regi Correction Value of S Size document. Unit=Step (S Size=131.7mm~158.0mm in Slow Scan
Direction)
710-026 M Size Side2 Lead Regi Adjust 250 217~283 Side 2 Lead Regi Correction Value of M Size document. Unit=Step (M Size=158.1mm~245.9mm in Slow Scan
Direction)
710-027 L Size Side2 Lead Regi Adjust 250 217~283 Side 2 Lead Regi Correction Value of L Size document. Unit=Step (L Size=246.0mm~460.0mm in Slow Scan
Direction)
710-800 ADF Static Jam Count Total (No Sensor
Sensed Jam)
0 0~65535 cumulative Jam Counter (Write not permitted)
710-801 ADF Static Jam Count Since Reset (No
Sensor)
0 0~65535 cumulative Jam Counter at the previous clearing (Write not permitted)
710-802 ADF Document Input Sensor Static
Jam Count Total
0 0~65535 cumulative Jam Counter (Write not permitted)
